Part Number 000014141 Rev 11 12/23 17
Section 2 Installation
Bin Installation Requirements
• The installation area must be capable of
supporting the combined weight of the
equipment and product.
• All ice machines installed on a bin
require an ice deflector.
• Manitowoc bins have a deflector
installed and require no modifications
when used with a forward-facing
evaporator.
• Ice machines with multiple evaporators
require a deflector kit.
• Align sides and back of ice machine with
sides and back of bin when placing ice
machine on bin.
• Optional sales kits are available to adapt
various sized or multiple ice machines on
large bins.
Bin Installation
NOTE: When using casters, the units must
be tethered or secured to comply with all
applicable codes. Swivel casters must be
mounted on the front and rigid casters
must be mounted on the rear. Lock the
front casters after installation is complete.
1. Remove threaded plug from drain
fitting.
2. Screw the leveling legs onto the
bottom of the bin.
3. Screw the foot of each leg in as far as
possible.
4. Move the bin into its final position.
5. Level the bin to assure that the bin
door closes and seals properly. Use a
level on top of the bin. Turn the base
of each foot as necessary to level the
bin.
6. Inspect bin gasket prior to ice machine
installation. (Manitowoc bins come
with a closed cell foam gasket installed
along the top surface of the bin.)
7. Remove all panels from ice machine
before lifting and installing on bin.
Remove front panel, top cover, left and
right side panels.
