Installation Section 2
CONDENSING UNITS
Additional Refrigerant
Ice
Machine
Remote
Condenser
Additional
Refrigerant Added
to Nameplate
Charge for 50'
to 100' (15 to 30
Meter) Line Sets
IF0600C CVDF0600 1.5 lbs - 680 g
IBF0620C CVDF0600 1.5 lbs - 680 g
IBF0820C CVDF0900 1.5 lbs - 680 g
IF0900C CVDF0900 2.0 lbs - 907 g
IBT1020C CVDT1200 2.0 lbs - 907 g
IT1200C CVDT1200 2.0 lbs - 907 g
IF1400C CVDF1400 2.0 lbs - 907 g
IT1430C CVDT1400 2.0 lbs - 907 g
IF1800C CVDF1800 2.0 lbs - 907 g
IT1830C CVDT1800 2.0 lbs - 907 g
IF2100C CVDF2100 4.0 lbs - 1814 g
IT2130C CVDT2100 2.0 lbs - 907 g
Line Set / Model
Line Set
Suction
Line
Liquid
Line
Model
RC
21/31/51
5/8 inch
(16 mm)
3/8 inch
(10 mm)
IF0600C
IBF0620C
IBF0820C
IF0900C
IBT1020C
IT1200C
IT1430C
RC
20/30/50
3/4 inch
(19 mm )
1/2 inch
(13 mm)
IF1400C
IF1800C
IT1830C
IT2130C
RC
23/33/53
3/4 inch
(19 mm)
5/8 inch
(16 mm)
IF2100C
NOTE: All line sets must be insulated with
Armaflex:
1/2" (13 mm) Suction Line
1/4" (7 mm) Liquid Line
n
Warning
Installation of a QuietQube® Condensing
Unit may require the use of special
equipment for placement. Trained and
qualified personnel are required for proper
rigging and lifting. Holes are provided on
the corners of the condensing unit to allow
the use of lifting shackles.
Notice
Manitowoc remote systems are only
approved and warranted as a complete
new package. Warranty on the refrigeration
system will be void if a new ice machine
head section is connected to pre-existing
(used) tubing or condensing units or vice
versa.
