Part Number 000014141 Rev 11 12/23 29
Section 2 Installation
5. Check all fittings and valve caps for
leaks and reinstall and tighten caps.
6. Interconnecting line voltage wiring
is used to energize and de-energize
the condenser fan motor. The remote
condenser voltage matches the ice
machine head section voltage.
Interconnecting Wiring Connections
Ice Machine Remote Condenser
L1 F1
L2 F2
Installation is finished for remote
condenser models. Proceed to page 34
for start-up procedure.
