22 Part Number 000014141 Rev 11 12/23
Installation Section 2
QuietQube® Head Sections
Ice Machine
Voltage/Phase/
Cycle
Maximum Fuse/
Circuit Breaker
Minimum Circuit
Amps
Total Amps
Ice Beverage
Models
115/1/60 15 amp - - - 1.2
230/1/50 15 amp - - - 1.0
All Non IB
QuietQube®
Models
115/1/60 15 amp 1.2 - - -
230/1/50 15 amp 1.0 - - -
CVD Condensing Units
Condensing
Unit
Voltage/Phase/
Cycle
Maximum
Fuse/Circuit
Breaker
Minimum
Circuit Amps
Minimum Wire Size Required
by Manitowoc
CVDF0600
208-230/1/60 15 amp
11.6
¹9.0
#12 Solid Copper Conductor
208-230/3/60 15 amp
10.2
¹6.6
#12 Solid Copper Conductor
230/1/50 15 amp 10.2 #12 Solid Copper Conductor
CVDF0900
208-230/1/60 20 amp 11.5 #10 Solid Copper Conductor
208-230/3/60 15 amp 7.1 #12 Solid Copper Conductor
230/1/50 20 amp 8.7 #10 Solid Copper Conductor
CVDT1200
208-230/1/60
25 amp
20 amp
14.8
¹13.3
#10 Solid Copper Conductor
208-230/3/60 15 amp
9.3
¹11.1
#12 Solid Copper Conductor
230/1/50 20 amp 12.8 #10 Solid Copper Conductor
CVDF1400
208-230/1/60 20 amp
14.2
¹11.1
#10 Solid Copper Conductor
208-230/3/60 15 amp 11.1 #12 Solid Copper Conductor
CVDT1400
208-230/1/60 20 amp 13.1 #10 Solid Copper Conductor
208-230/3/60 15 amp 10.4 #12 Solid Copper Conductor
CVDF1800
208-230/1/60 30 amp 19.2 #8 Solid Copper Conductor
208-230/3/60 20 amp 13.3 #10 Solid Copper Conductor
230/1/50 40 amp 25.0 #8 Solid Copper Conductor
CVDT1800
208-230/1/60 25 amp 16.7 #10 Solid Copper Conductor
208-230/3/60 20 amp 13.5 #10 Solid Copper Conductor
230/1/50 25 amp 14.9 #10 Solid Copper Conductor
CVDF2100
208-230/1/60 50 amp 40.0 #6 Solid Copper Conductor
208-230/3/60 30 amp 30.0 #10 Solid Copper Conductor
CVDT2100
208-230/1/60 40 amp 24.1 #8 Solid Copper Conductor
208-230/3/60 30 amp 18.3 #10 Solid Copper Conductor
¹Alternate compressor - Refer to model serial tag on ice machine to verify your minimum circuit amps.
