SETUP AND INSTALLATION MLC90A-1/MLC100-1 OPERATOR MANUAL
4-8
Published 12-10-19, Control # 258-05
Figure 4-5
View A
View B
View C
View D
View E
View F
WORKING
Item Description
1Trailer
2 Safety Pin (qty 8)
3 Storage Lug
4 Step (qty 8)
5Pin
6
Hitch Pin with Hair-Pin Cotter (qty 5 left)
Hitch Pin with Hair-Pin Cotter (qty 7 right)
7 Platform (qty 2, sliding)
8
Platform (qty 2 left, folding)
Platform (qty 6 right, folding)
SStored
W Working
STORED
