SETUP AND INSTALLATION MLC90A-1/MLC100-1 OPERATOR MANUAL
4-24
Published 12-10-19, Control # 258-05
Figure 4-15
View A
View B
View C
Item Description
1 Chain Lifting Sling (Manitowoc furnished)
2 Hook-and-Weight Ball
3 Counterweight Tray
4 Counterweight Box
• Qty 2 for Series 1
• Qty 4 for Series 2
5 Connecting Pin with Safety Pins (Qty 4 or 8)
6 Handling Pendants and Links (stored on tray)
7 Grab Handle (Qty 2 each box)
