SETUP AND INSTALLATION MLC90A-1/MLC100-1 OPERATOR MANUAL
4-68
Published 12-10-19, Control # 258-05
Item Description
1 Boom Butt
2 Boom Insert
3 Bottom Connector Pin (Qty 2)
Figure 4-44
View D
View A
View B
View C
(STORED)
