SETUP AND INSTALLATION MLC90A-1/MLC100-1 OPERATOR MANUAL
4-70
Published 12-10-19, Control # 258-05
Figure 4-45
Item Description
1 Equalizer
3 Insert Pendant (Qty 2)
2 Pendant Pin (Qty 2)
4 Boom Butt
5 Boom Insert
6 Top Connector Pin with Safety Pin (Qty 2)
7 Rope Guide
View A
View B
