OPERATING CONTROLS AND PROCEDURES MLC90A-1/MLC100-1 OPERATOR MANUAL
3-6
Published 12-10-19, Control # 258-05
Pin, Disengage Swing
Pin, Engage Swing Left
Regen (Tier 4), Inhibit Swing Right
Regen (Tier 4), Initiate Travel Forward—Left Crawler
Setup Travel Forward—Right Crawler
Speed, Fast Travel Reverse—Left Crawler
Speed, Slow Travel Reverse—Right Crawler
Stop, Emergency USB
Table 3-2. Symbol Identification — Control Consoles
