Part Number 020002365 08/25/2015 31
Typical System
8 Valve Soda Tower
6 Valve Soda Tower
Conduit (In Wall)
BIB Pumps
Water Booster
Air Compressor
Conduit
CO
2
Panel
Multiplex
Refrigeration Unit
Water Filters
BIB Rack
Bag-In-Box
(BIB) Syrup
CO
2
Tank
Section 3
Operation
