34 Part Number 020002365 08/25/2015
Operation Section 3
PROGRAM MODE 1
To enter, press and hold switch for 3 seconds.
• 0001 will display indicating Mode 1
• Wait 3 seconds C000 will display
• Press and hold Carb A switch — Display will indicate
one of the following:
ū CA00 — Low and High Probes are open
(carbonator motor is energized)
ū CA11 — Low and High Probes are closed
(carbonator motor is de-energized)
ū CA01 — Low Probe closed (Motor will still be on)
• Press and hold Carb B switch — Display will indicate
one of the following:
ū Cb00 — Low and High Probes are open
(carbonator motor is energized)
ū Cb11 — Low and High Probes are closed
(carbonator motor is de-energized)
ū Cb01 — Low Probe closed (Motor will still be on)
• Press and hold COMP/AGIT switch — Display will
indicate one of the following:
ū CL 0 — Water level low
ū CL 1 — Water level OK
• Press PGM Switch 1 time — F000 will display:
ū Press COMP/AGIT to toggle between F000
(Fahrenheit) and FC00 (Centigrade)
ū Press and hold Carb A switch — Display will
indicate Water Bath Temperature
ū Press and hold Circ A switch — Display will
indicate Liquid Line Temperature
ū Press and hold Circ B switch — Display will
indicate Suction Temperature
• Press PGM Switch twice or a second time — P000 will
display
ū Press and hold Carb A switch — Display will
indicate Water Pressure
PROGRAM MODE 2
Add circulation pumps C and/or D.
• Press PGM button for 3 seconds - Display shows 0001.
• Press PGM button again in less than 3 seconds - Display
shows 0002 program mode 2.
• Wait 3 seconds - Display shows -002 = Factory default
setting.
ū Pressing CIRC A button energizes/de-energizes
pump A
ū Pressing CIRC B button energizes/de-energizes
pump B
• Program CIRC C - Press CARB A button - Display shows
-102 = Carb A button energizes/de-energizes pump C
• Program CIRC D - Press CARB B button - Display shows
-012 = Carb B button energizes/de-energizes pump D
• Four pumps shows -112.
NOTE: CIRC C motor needs to be connected to CARB A
output connection on the ERC board & CIRC D motor to
CARB B output connection.
Press and hold PGM switch for 3 seconds to save settings
and exit program mode.
PROGRAM MODE 3
This mode is for Beermaster units only and not used on
Soda or Water refrigeration systems. To turn this mode ON/
OFF do the following;
• Press PGM button for 3 seconds - Display shows 0001.
• Press PGM button twice in less than 3 seconds to enter
program mode 3 - Display shows 0003
• Wait 3 seconds, display shows -003
• Press the COMP/AGIT button once to toggle to BEER
MODE.
ū BEER MODE ON = Display shows 1273
ū BEER MODE OFF = Display shows 1- -3
,
Caution
If BEER MODE is ON, the water bath will be set to 27°F
factory default temperature setpoint and freeze. Do not
place Soda or Water refrigeration units in BEER MODE.
• Press and hold PGM switch for 3 seconds to save
settings and exit program mode.
