HOIST NBT40 SERVICE MANUAL
5-10 Published 8-01-2017 Control # 287-11
Hoist Parts List
Item Qty Description Item Qty Description
1 18 CAPSCREW
36-2 3 Planet Gear
2 2 Support rod
36-3 3 Planet Pin
3 1 Counterbalance Block
36-4 3 Retaining Ring
41Gear Set
36-5 1 Plate
4-1 1 Carrier
36-6 3 Needle Bearing
4-2 3 Planet Gear
36-7 6 Fitting, Str Adapter
4-3 3 Planet Pin
37 1 Capscrew
4-4 3 Retaining Ring
38 4 Input Driver
4--5 1 Plate
39* 1 Bushing
4-6 6 Bearing
40 1 Pipe Plug
4-7 3 Spacer
42 2 Motor
4-8 6 Race
43 1 Straight Adapter
51Drum
44 1 Tee Fitting
6 2 Race
45 1 90 deg Adapter
7 1 Seal Kit
46 1 90deg Adapter
8 1 Input Sun Gear
47 1 Capscrew
9 14 Capscrew
50 4 Flange
10 1 Brake Piston
51 1 Pind
11 4 Capscrew
52 5 Retaining Ring
12 1 Tubing
54 1 DRI/MWI (Minimum Wrap Indicator)
13 1 Brake Driver
56 1 Base
14 2 Race
57 1 Capscrew
15 2 Retaining Ring
58 4 Nut
16 1 Output Sun Gear
63 4 Screw
17 2 Bushing
64 2 Cordset
18 7 Friction Disk
65 1 Cable packer
19 8 Stator Plate
65-1 2 Bearing
20 1 Brake Cover
65-2 2 Arm
21 1 Brake Housing
65-3 1 Roller
22 1 Tubing
65-4 1 Roller
24 12 Brake Spring
65-5 2 Capscrew
25 1 Gear Insert
65-6 2 Ball Bearing
27 1 Side Plate
65-7 1 Spring, LH
28 2 Ball Bearing
65-8 1 Spring RH
29 1 Sideplate
68 1 CB Valve
30 2 Breather
76 1 Plug
31 4 Capscrew
81 1 Cordset, DRI/MWI
32 1 Output Shaft
82 1 Shaft, Drive, DRI
33 1 Plug
84 1 Roller
34 1 Clutch
85 2 Bushing
35 1 Retaining ring
86 1 Connector
36 1 Input Gear Set
36-1 1 Carrier
Reference Only
