Part Number 000001130 12/08 3-1
Section 3
Operation
Component Identification
ICE DAMPER
WATER TROUGH
WATER PUMP
ICE THICKNESS
PROBE
EVAPORATOR
(Q210/Q270 SHOWN)
DISTRIBUTION
TUBE
FLOAT VALVE
SIPHON CAP
BIN SWITCH
ON/OFF/WASH
TOGGLE
SWITCH
COMPRESSOR COMPARTMENT
ACCESS SCREWS
CONDENSER AIR
FILTER
ON/OFF/WASH
TOGGLE
SWITCH
COMPRESSOR COMPARTMENT
ACCESS SCREWS
CONDENSER AIR
FILTER
