50 Part Number 80-01111-9 7/10
Disassembly
• Twist both of the inner tube ends until the tabs line
up with the keyways.
• Pull the inner tube ends outward.
Q210/Q270 Water Distribution Tube Disassembly
SV1211
INNER
TUBE
TAB
KEYWAY
INNER
TUBE
