Part Number 80-01111-9 7/10
51
Q130 Mode
ls
Q130 W
ater Distrib
ution T
ube Removal
•
Loosen the two
thumbscrews, which secure
the distribution tube.
•
Lift the
distrib
ution tube up off the
thumbscrews.
Disassembly
•
T
wist
the barbed end
until the
tab lines up with
the keyway
.
•
Pull the inner tube end
outward.
Q130 W
ater D
istribution T
ube Disasse
mbly
SV1731C
THUMBSCREW
REMOVE IC
E
THICKNE
SS PROB
E
THUMBSCREW
DISTRIBUTION
TUBE
SV1741
KEYWAY
TAB
50
52
