52
Part Number 80-01111-9
7/10
F
.
Remove the Float V
alve
•
T
urn the
splash shield
counterclockwise o
ne or
two turn
s.
FLOAT V
ALVE REMOVAL
•
Pull the float valve forward
an
d off the mounting
bracket.
•
Disconnect the
water
i
nlet
tube
from
th
e float
valve
at the compression
fitting.
•
Remove the cap and filter
screen for cleaning.
SV1695
-2
FLOAT V
ALVE
BRACKET
COMPRESSION
FITTING
CAP AND
FILTER
SCREEN
SP
L
A
S
H
SHIELD
SHUT-OFF
VA
L
V
E
FLOAT
51
53
