Part Number STH039 8/13 17
Component Identification
Evaporator Compartment
ICE THICKNESS
PROBE
DISTRIBUTION
TUBE
EVAPORATOR
WATER
TROUGH
ICE
DAMPER
WATER
PUMP
SV1694A
THUMBSCREWS
WATER
PUMP
COVER
WATER
PUMP
