26 Part Number STH039 8/13
Step 6 Remove parts for cleaning.
A. Remove Two Thumbscrews and Water
Pump Cover.
B. Remove the Vinyl Hose Connecting the
Water Pump and Water Distribution Tube
C. Remove Water Pump
• Disconnect the water pump power cord
• Loosen the screws securing the pump-
mounting bracket to the bulkhead
• Lift the pump and bracket assembly off
the mounting screws.
Water Pump Removal
To Next Page
