28 Part Number STH039 8/13
E. Remove the Water Distribution Tube
Water Distribution Tube Removal
• Loosen the two thumbscrews, which secure the
distribution tube.
• Lift the right side of the distribution tube up off the
locating pin, then slide it back and to the right.
Do not force this removal. Be sure the
locating pin is clear of the hole before sliding
the distribution tube out.
