Table 2-1. Q320/370/420 Ice Machines
Table 2-2. Q200 - Q1000 Ice Machines
Ice Machine
Voltage
Phase
Cycle
Air-Cooled Water Cooled
Maximum Fuse/
Circuit Breaker
Minimum
Circuit Amps
Maximum Fuse/
Circuit Breaker
Minimum
Circuit Amps
Q320
115/1/60 15 11.2 15 10.5
208-230/1/60 15 4.8 15 4.2
230/1/50 15 5.2 15 4.7
Q370
115/1/60 20 12.9 20 12.2
208-230/1/60 15 6.2 15 5.8
230/1/50 15 6.2 15 5.8
Q420
115/1/60 20 12.3 20 11.4
208-230/1/60 15 7.8 15 7.4
230/1/50 15 6.3 15 5.9
Ice Machine
Voltage
Phase
Cycle
Air-Cooled Water Cooled Remote
Maximum
Fuse/Circuit
Breaker
Minimum
Circuit Amps
Maximum
Fuse/Circuit
Breaker
Minimum
Circuit Amps
Maximum
Fuse/Circuit
Breaker
Minimum
Circuit Amps
Q200
115/1/60 15 11.6 15 10.9 N/A N/A
208-230/1/60 15 5.4 15 4.8 N/A N/A
230/1/50 15 5.2 15 4.9 N/A N/A
Q280
115/1/60 20 12.6 20 11.7 N/A N/A
208-230/1/60 15 5.7 15 5.2 N/A N/A
230/1/50 15 5.7 15 5.2 N/A N/A
Q450
115/1/60 20 12.8 20 11.9 20 13.6
208-230/1/60 15 7.8 15 7.4 N/A N/A
230/1/50 15 6.1 15 5.7 N/A N/A
Q600
208-230/1/60 15 9.2 15 8.7 15 9.3
230/1/50 15 9.2 15 8.8 15 9.4
Q800
208-230/1/60 20 12.1 20 11.4 20 11.9
208-230/3/60 15 8.9 15 8.2 15 8.9
230/1/50 20 12.0 20 10.6 20 11.2
Q1000
208-230/1/60 20 14.3 20 13.2 20 14.2
208-230/3/60 15 9.8 15 8.8 15 9.9
230/1/50 20 15.6 20 14.2 20 14.6
Q1300
208-230/1/60 30 19.5 30 18.1 30 19.8
208-230/3/60 20 13.1 20 11.6 20 12.7
230/1/50 30 15.7 30 14.3 30 14.7
380-415/3/50 N/A N/A N/A N/A 15 7.3
Q1600
208-230/1/60 N/A N/A 30 17.2 30 18.2
208-230/3/60 N/A N/A 20 11.0 20 12.0
230/1/50 N/A N/A N/A N/A N/A N/A
380-415/3/50 N/A N/A N/A N/A N/A N/A
Q1800
208-230/1/60 40 28.1 40 26.7 40 26.9
208-230/3/60 20 15.5 20 14.1 20 13.9
230/1/50 40 23.3 40 21.9 40 22.2
380-415/3/50 N/A N/A N/A N/A 15 9.1
