TOTAL SYSTEM REFRIGERANT CHARGES
NOTE: All ice machines on this list are charged using
R-404A refrigerant.
Additional Refrigerant Charges
For line sets between 50’ - 100’.
Important
This information is for reference only. Refer to the
ice machine serial number tag to verify the system
charge. Serial plate information overrides
information listed on this page.
Series Version Charge
S300
Air-Cooled 18 oz.
Water-Cooled 15 oz.
S320
Air-Cooled 20 oz.
Water-Cooled 19 oz.
S420
Air-Cooled 21 oz.
Water-Cooled 20 oz.
S450
Air-Cooled 21 oz.
Water-Cooled 20 oz.
S500
Air-Cooled 26 oz.
Water-Cooled 22 oz.
Remote 6 lb.
S600
Air-Cooled 32 oz.
Water-Cooled 28 oz.
Remote 6.5 lb.
S850
Air-Cooled 36 oz.
Water-Cooled 32 oz.
Remote 8.5 lb.
S1000
Air-Cooled 36 oz.
Water-Cooled 38 oz.
Remote 8.5 lb.
S1200
Air-Cooled 38 oz.
Water-Cooled 42 oz.
S1400
Air-Cooled 44 oz.
Water-Cooled 40 oz.
Remote 11 lb.
S1600
Air-Cooled 48 oz.
Water-Cooled 48 oz.
Remote 11.5 lb.
S1800
Air-Cooled 52 oz.
Water-Cooled 48 oz.
Remote 12.5 lb.
Series
Nameplate
Charge
Refrigerant
to be added
for 50’ - 100’
line sets
Maximum
System Charge
Never Exceed
S500
6 lb.
(96 oz.)
1.5 lb.
(24 oz.)
7.5 lb.
(120 oz.)
S600
6.5 lb.
(104 oz.)
1.5 lb.
(24 oz.)
8.0 lb.
(128 oz.)
S850/S1000
8.5 lb.
(136 oz.)
2 lb.
(32 oz.)
10.5 lb.
(168 oz.)
S1400
11 lb.
(176 oz.)
2 lb.
(32 oz.)
13 lb.
(208 oz.)
S1600
11.5 lb.
(184 oz.)
2 lb.
(32 oz.)
13.5 lb.
(216 oz.)
S1800
12.5 lb.
(200 oz.)
1 lb.
(16 oz.)
13.5 lb.
(216 oz.)
