Section 6 Electrical System
Part Number 80-1480-3 6-37
ELECTRONIC CONTROL BOARD
Control Board
SV3129
AC LINE VOLTAGE
ELECTRICAL
PLUG (NUMBERS
MARKED ON
WIRES)
MAIN FUSE (7A)
AUTOMATIC CLEANING
SYSTEM (AuCS) PLUG
ICE THICKNESS
PROBE (3/16''
CONNECTION)
WATER LEVEL PROBE
DC LOW VOLTAGE
ELECTRICAL PLUG
(NUMBERS MARKED ON
WIRES)
WATER PROBE LIGHT (GREEN)
LEFT BIN LIGHT (GREEN)
HARVEST LIGHT (RED)
REMOTE BIN
CLEAN LIGHT (YELLOW)
WATER PURGE
ADJUSTMENT
AIR COMPRESSOR
(NOT USED ON
ALL MODELS)
RIGHT BIN LIGHT (GREEN)
PRIMARY POWER SUPPLY
N 115V
L2 208-230V
REMOTE BIN LIGHT (GREEN)
ICE PROBE LIGHT (GREEN)
SAFETY LIMIT 1 LIGHT (RED)
SAFETY LIMIT 2 LIGHT (RED)
