Manitowoc S User Manual

Electrical System Section 6
6-24
Part Number 80-1480-3
S850/S1000 - REMOTE - 3 PHASE
SV3159
(89)
(55)
(88)
(42)
High Pressure
Cutout
Harvest Valve
Dump Valve
Water Pump
(20)
(21)
(22)
(74)
Ice Thickness
Probe
Water Level Probe
Control
Board
(61)
(60)
(57)
(98)
(99)
(76)
(81)
(75)
(77)
(80)
(26)
(25)
(58)
(59)
Contactor Coil
(56)
Trans.
Fuse (7a)
Low DC
Voltage
Plug
L1
(51)
F1
Fan Motor
Run Capacitor
Compressor
L1
Ground
(2)
(6)
(5)
(1)
(7)
(4)
L2
Air Compressor
(When Used)
Bin Switch
Clean
OFF
ICE
(2)
(1)
(6)
(8)
(9)
Contactor
Contacts
(75)
L2
L3
L2L3
T2
T1
T3
Liquid Solenoid
F2
(83)
(22)
(82)
(78)
(79)
(82)
(74)
(75)
HPR Valve
Water Valve
Clean
Left Bin
Right Bin
Wtr Probe
Rmt Bin
Ice Probe
Harvest
SL-2
SL-1
