Manitowoc S User Manual

Electrical System Section 6
6-26
Part Number 80-1480-3
S1400/S1600/S1800 - SELF-CONTAINED - 3 PHASE
(42)
CONTROL BOARD
CLEAN
OFF
ICE
BIN
SWITCH
(8)
LOW D.C.
VOLTAGE
PLUG
CONTACTOR
COIL
(56)
TERMINATES AT
PIN CONNECTION
(74)
PUMP
WATER
(58)
ICE THICKNESS
PROBE
WATER LEVEL
PROBE
SOLENOID
DUMP
(81)
(75)
(76)
LH HARVEST
SOLENOID
(87)
(77)
VALVE
WATER
(60)
(61)
(22)
(21)
(7)
(2)
(1)
(6)
(5)
HIGH PRESSURE
CUTOUT
(55)
(89)
(88)
(20)
(59)
CLEAN
LEFT BIN
RIGHT BIN
RMT BIN
WTR PROBE
ICE PROBE
HARV
SL-1
SL-2
AIR
COMPRESSOR
WHEN USED
(6)
(2)
(1)
(9)
(25)
(26)
L2
AIR
COMP
FAN CYCLE CONTROL
T3
L2
L3
COMPRESSOR
T1
T2
(51)
(85)
(86)
CONTACTS
CONTACTOR
L1
L2
L3
L1
(AIR COOLED ONLY)
FAN MOTOR
RUN CAPACITOR**
FUSE (7A)
TRANS.
(4)
(99)
(98)
(57)
RH HARVEST
SOLENOID
(80)
(88)
