Part Number 80-1479-3 7/10 217
S600N
All Remote Air-Cooled Condenser Models
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
-20/-29 to 70/21 7.9-9.4 8.8-10.3 9.3-10.9
1-2.5
80/27 7.9-94 8.9-10.5- 9.5-11.2
90/32 8.1-9.5 8.9-10.5 9.7-11.4
100/38 8.8-10.3 9.7-11.4 10.4-12.2
110/43 9.7-11.4 10.6-12.5 11.4-13.4
Air Temp. Entering
Condenser
°F/°C
Water Temperature °F/°C
12
1 Based on average ice slab weight of 4.12 - 4.75 lb
2 Ratings with JC0895 condenser dice or half dice cubes
50/10 70/21 90/32
-20/-29 to 70/21 630 580 550
80/27 630 570 530
90/32 620 570 540
100/38 580 530 500
110/43 530 490 460
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
-20/-29 to
50/10
210-240 40-29 130-190 62-80
70/21 225-250 50-30 130-200 75-95
80/27 245-275 52-31 130-200 75-100
90/32 245-285 52-32 135-200 80-100
100/38 260-315 55-32 140-200 80-100
110/43 290-365 60-34 170-200 85-100
