Ice Machine Clearance Requirements
S300
Self-Contained
Air-Cooled
Self-Contained
Water-Cooled
Top/Sides 16" (40.6 cm) 8" (20.3 cm)
Back 5" (12.7 cm) 5" (12.7 cm)
S320/S450/S500/
S600/S850/S1000
Self-Contained
Air-Cooled
Water-Cooled and
Remote*
Top/Sides 8" (20.3 cm) 8" (20.3 cm)
Back 5" (12.7 cm) 5" (12.7 cm)
S420
Self-Contained
Air-Cooled
Water-Cooled and
Remote*
Top/Sides 12" (30.5 cm) 8" (20.3 cm)
Back 5" (12.7 cm) 5" (12.7 cm)
S1200
Self-Contained
Air-Cooled
Water-Cooled and
Remote*
Top 8" (20.3 cm) 8" (20.3 cm)
Sides 12" (30.5 cm) 8" (20.3 cm)
Back 5" (12.7 cm) 5" (12.7 cm)
S1400/S1600/
S1800
Self-Contained
Air-Cooled
Water-Cooled
and Remote*
Top/Sides 24" (61.0 cm) 8" (20.3 cm)
Back 12" (30.5 cm) 5" (12.7 cm)
*
* There is no minimum clearance required for water-cooled or
remote ice machines. This value is recommended for efficient
operation and servicing only.
S3300
**
** S3300 - 24” on all sides is recommended to allow access without
moving the bin/ice machine.
Water-Cooled
Top/Sides 8" (20.3 cm)
Back 24" (61.0 cm)
