Manitowoc S300 - S1000 Series

Part Number 80-1479-3 7/10 227
S1000 SERIES
S1000A
All Self-Contained Air-cooled Before Serial Number
110697023
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 6.3-7.3 6.9-8.0 7.6-8.8
.75-2.0
80/27 6.9-8.1 7.6-8.8 8.4-9.6
90/32 7.8-9.0 8.5-9.8 9.4-10.8
100/38 9.3-10.7 10.2-11.7 11.0-12.7
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 5.75 - 6.50 lb.
50/10 70/21 90/32
70/21 1060 990 910
80/27 980 910 840
90/32 890 830 760
100/38 770 710 660
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10
195-255 50-26 130-145 70-90
70/21 220-275 50-26 130-145 70-90
80/27 235-290 52-28 150-165 75-95
90/32 265-330 58-28 165-185 85-110
100/38 300-360 60-31 180-210 95-120
110/43 330-415 66-32 215-235 115-145
