Grove Published 07-06-2017, Control # 406-03 6-19
CD5520/YB5520 OPERATOR MANUAL MAINTENANCE
Item Description
1 Hoist Tension Spring
2 Hoist Hose Connections
3 Pivot Shaft
4 Wire Rope
5 Hose Connections inside turntable
6
All Hardware, Clips, Pins, Hose Connections
not painted O/R Pins, Clips
7 Boom Nose Pins, Clips
8 Headache Ball/Hook Block
9 Turntable Bearing Fasteners
10 O/R Pins, Clips
11 Hook block Tiedown Cable
12 O/R Hose Connections
13 Entire underside of unit
14 Powertrain Hardware inside compartment
15 Boom Extension Pins, Clips - Option
16 Boom Extension Hanger Hardware - Option
