Grove Published 07-06-2017, Control # 406-03 1-1
CD5520/YB5520 OPERATOR MANUAL INTRODUCTION
1
SECTION 1
INTRODUCTION
SECTION CONTENTS
The Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Directional Reference. . . . . . . . . . . . . . . . . . . . . . . 1-1
Serial Number Plate . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Delivery Report . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Customer Support. . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Noise/vibration test results . . . . . . . . . . . . . . . . . . 1-2
Noise Level Test Results. . . . . . . . . . . . . . . . . . . . 1-2
Vibration Level Test Results . . . . . . . . . . . . . . . . . 1-2
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
General Crane Design. . . . . . . . . . . . . . . . . . . . . . 1-2
Nomenclature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
THE MANUAL
This operator’s manual provides the information you need to
correctly operate and maintain the crane.
NOTE: Before you operate the crane, carefully read this
manual completely, so you will understand the
safety instructions and the operation of the controls
and safety equipment. You must comply with all
DANGER, WARNING, and CAUTION notices.
They are for your benefit.
DIRECTIONAL REFERENCE
All references to the right side, left side, front, and rear are
given from the operator’s seat looking in a forward direction.
SERIAL NUMBER PLATE
The serial number of the crane is stamped on the serial
number plate located behind the operator’s seat. See
Figure 1-1. Components, such as the pump, transmission,
engine, axles, etc., have their own serial number plates that
will be found on the housing of the component.
NOTE: The replacement of any part of this product with
anything other than a manufacturer’s authorized
replacement part may adversely affect the
performance, durability, or safety of this product
and will void the warranty. The manufacturer
assumes no liability for unauthorized replacement
parts which adversely affect the performance,
durability, or safety of this product.
FIGURE 1-1
p0294
Serial Number Plate
Reference Only
