Manitowoc Shuttlelift CD5520

Grove Published 07-06-2017, Control # 406-03 8-5
CD5520/YB5520 OPERATOR MANUAL SPECIFICATIONS
8
Length....................................................................................................97.5 m (320 ft)
CE
Diameter.................................................................................................14 mm
Type .......................................................................................................8 x 25 EIPS-IWRC
Length....................................................................................................97.5 (320 ft)
Wire Rope (Optional Below Deck Winch):
Diameter.................................................................................................11.1 mm (7/16 in)
Length....................................................................................................35.1 m (115 ft)
TRANSMISSION
Model .........................................................................................................International - Powershift
Type .......................................................................................................4 speed forward and 4 speed reverse
TORQUE CONVERTER
Model .........................................................................................................Borg and Beck S-11
Type ...........................................................................................................Hydraulic
FRONT AXLE DRIVE
Type ...........................................................................................................International Transmissions Limited
Drive Type ..................................................................................................2wd /4wd Drive/Steer
Model .........................................................................................................SD80 - Center Drive Head
REAR AXLE DRIVE
Type ...........................................................................................................International Transmissions Limited
Drive Type ..................................................................................................Drive/Steer in 4wd
Model .........................................................................................................SD80 - Offset Drive Head
REAR AXLE NON-DRIVE
Type ...........................................................................................................International Transmissions Limited
Drive Type ..................................................................................................Non-drive with steer in 2wd
Model .........................................................................................................SD80 - Offset with No Drive Head
OUTRIGGERS
Type ...........................................................................................................Hydraulic
Construction...............................................................................................Welded box
TIRES
Size...................................................................................................................12.00R20
Type ..................................................................................................................Radial
Air pressure.......................................................................................................828 kPa (120 psi)
Wheel nut torque...............................................................................................680 Nm (500 lb-ft)
WEIGHT
Crane (Basic - GVW).........................................................................................16.494 kg (36,364 lb)
TRAVEL SPEEDS
TWO-WHEEL STEER
• 1st gear ......................................................................................................6.4 km/hr (4 mph)
• 2nd gear.....................................................................................................11.3 km/hr (7 mph)
