SAFETY INFORMATION CD5520/YB5520 OPERATOR MANUAL
2-16 Published 07-06-2017, Control # 406-03
Is the load to be lifted less than allowable load?
8,000 kg 12,040 kg YES
Is Awr
(load)
less than Awr
(allow)
?
19.83 m
2
14.45 m
2
NO
Conclusion: This load is NOT
permissible to lift in wind
speed up to 20.1 m/s, but permitted to lift at a reduced wind
speed calculated as follows:
Ratio = 1.37
From Table 2-5, the maximum permissible wind speed at
ratio of 1.37 (rounded to next higher table value of 1.4) is
17.0 m/s.
Conclusion: This load is permissible to lift in wind speed up
to 17.0 m/s only.
