Part Number: 040006977 09/22 19
Section 4 Maintenance
SANITIZINGING PROCEDURE
NOTE: Sanitizing can be performed independently and more
frequently than de-scaling if desired.
Step 10 Mix 60 ml of sanitizer with 12 l of water in a plastic
or stainless steel container.
Sanitizer Water
60 ml (2 oz) 12 L (3 gal)
Step 11 Remove Water Curtain and Ice Chute as described
in Section 3 “Componet Removal” on page 12.
Step 12 Take all components to sink and with 10 liters
Sanitizer/Water mixture sanitize all components with a soft
nylon brush or cloth. Do not rinse components.
Step 13 Use brush or cloth to sanitize the inside of ice bin.
Scrub inside of door, door track, bin, water sump, water
distribution assembly and evaporator moldings. Do not rinse.
Step 14 Replace sump drain over flow tube, and transfer
remaining 2 liters of solution to the sump trough. Replace all
components.
Step 15 To start a standard sanitizing cycle, press the toggle
switch to WASH position and hold for 5 seconds.
Step 16 Wait until the cleaning cycle is complete
(approximately 13.5 minutes). Remove water curtain and ice
chute Remove over flow tube from water sump and allow
all water to drain from sump. Replace drain plug. Press the
toggle switch to WASH position and hold for 5 seconds to
start a rinsing cycle.
Step 17 Wait until the rinsing cycle is complete
(approximately 12 minutes). Remove water curtain, ice
chute, water sump over flow tube. Drain water from sump
and replace tube.
Step 18 Replace all parts.
Step 19 Place toggle switch to ON position,ice machine will
go into ice making cycle.
NOTE: To terminate a standard cleaning cycle, press the
toggle switch to WASH position and hold more than 30
seconds
,
Caution
If the de-scaler /sanitizer solution has been poured into
the water trough, then the standard cleaning cycle must be
completed. Don’t terminate the cleaning cycle, or the ice
machine will not purges the remaining de-scaler /sanitizer
solution from the water trough.
Cleaning the Condenser
n
Warning
Disconnect electric power to the ice machine at the
electric service switch before performing maintenance on
equipment.
AIR‑COOLED CONDENSER
A dirty condenser restricts airflow, resulting in excessively
high operating temperatures. This reduces ice production
and shortens component life.
Clean the condenser at least every six months.
1. Remove Plastic Front Grill removing two Phillips head
screws. Clean Grill openings before replacing.
2. Clean the outside of the condenser with a soft brush
or a vacuum with a brush attachment. Clean from top
to bottom, not side to side. Be careful not to bend the
condenser fins.
3. Shine a flashlight through the condenser to check for dirt
between the fins. If dirt remains:
A. Blow compressed air through the condenser fins. Be
careful not to bend the fan blades.
B. If dirt or grease remains between fins, consult your
service representative.
n
Warning
The condenser fins are sharp. Use care when cleaning
them.
