BIN THERMISTOR (T3)
Function
The bin thermistor stops the ice machine when the bin
is full. When ice cubes contact the bin thermistor bulb
holder, the bin thermistor opens and stops the ice
machine. When ice cubes no longer contact the bin
thermistor bulb holder, the bin thermistor closes and
the ice machine starts.
The bin thermistor “temperature setting” determined
by the point of T2(liquid line thermistor) of when T1
(sump water thermistor) come down 2 °C, refer to the
Specifications Charts below for clearance.
Specifications
UG40/UG50/YG65
UG18/UG20/UG30
UG80
T1 (°C) T2 (°C)
Shut down
(T3)
Go back
(T3)
≤2.0 T2≤28 ≤1.5 ≥2.0
≤2.0 28 ＜ T2≤56 ≤2.0 ≥3.5
≤2.0 56 ＜ T2 ≤3.0 ≥4.5
T1 (°C) T2 (°C)
Shut down
(T3)
Go back
(T3)
≤2.0 T2≤32 ≤1.7 ≥2.2
≤2.0 32 ＜ T2≤51 ≤2.2 ≥3.7
≤2.0 51 ＜ T2 ≤3.0 ≥4.5
T1 (°C) T2 (°C)
Shut down
(T3)
Go back
(T3)
≤2.0 T2≤37 ≤1.5 ≥2.0
≤2.0 37 ＜ T2≤56 ≤2.0 ≥3.5
≤2.0 56 ＜ T2 ≤3.0 ≥4.5
