Tubing Schematics

UG18/UG20/UG30/UG40/UG65 TUBING SCHE-

MATIC

1. Compressor

2. Hot Gas Valve

3. Condenser (Air or Water Cooled)

4. Receiver (Water Cooled Only)

5. Liquid Line Drier

6. Suction Accumulator with Heat Exchanger

7. Heat Exchanger

8. Capillary Tube

9. Evaporator
