Engine Parts Assembly
KEY # QTY MATERIAL
34 1 431 TINE SHAFT
35 2 430 WORM GEAR THRUST
WASHER
36 2 432 WORM GEAR BEARING
37 2 434 BEARING
38 2 435 BEARING SEAL RETAINER
39 1 438RA TINE ASSY - RT
40 1 438LA TINE ASSY - LT
41 2 418-1 TINE RETAINING HAIR PIN
42 1 400315 CARRYING HANDLE
43 1 400130 ENGINE FLANGE
44 1 400609 TINE LABEL
45 1 458 ROLLER BEARING
46 1 4058 MANTIS LABEL
47 2 410 CAP SCREW 1/4-20 X 1" LG.
48 4 972 LOCK NUT 1/4 - 20
49 2 470 1/4-20 X 3” BOLT
50 2 140 BOLT 1/4 - 20 X 3/8" LG.
51 2 377 HANDLE CLAMP
52 2 400509 BOLT
53 2 400523 KNOB
54 2 400230 PLUG
55 1 400010 TRANSMISSION ASSEMBLY
56 1 400132 BEARING
57 1 400131 CLUTCH DRUM
60 4 400511 M6 X 12 - FLANGED BOLT
* Also in Key #55
KEY # QTY MATERIAL
1 1 400257 TRIGGER HANDLE
ASSM. RH
2 1 400255 HANDLE ASSM. LH
6 2 400224 LOWER HANDLE -
FOLD DOWN
7 1 400620 LABEL
8 1 148 HANDLE BRACE
12 1 910502 10-32 X 3/4 -
FLANGED BOLT
13 2 478 THROTTLE CLIP
20 1 465 FENDER GUARD
21 1 400911 ENGINE ASSY - 25
CC
4 STROKE
22* 1 468 DRIVE SHAFT
23 1 466 WORM GEAR
HOUSING
24 1 436 GASKET
25 1 437A HOUSING COVER
26 4 651 RD. HD. SELF
TAPPING SCREW
27 1 423 ROLLER BEARING
28 2 425 WORM BEARING RACE
29 1 424 WORM THRUST
BEARING
30 1 422 WORM SHAFT
31 1 426 WORM DISK
32 1 428 RETAINING RING
33 1 429 WORM GEAR
Classic 4-Cycle Tiller Operator/Parts Manual
