Step 5
Step 6
Step 7
Holding the nut in place, tighten the screw
on each side with a flat head screwdriver.
Place the handle cross brace (key #46)
between the handles and lay the throttle
cable and wire into the clips of the right-
hand handle brace.
Line up the holes in the brace with the holes
in the handle tubing and attach the brace
with one screw (key #1) and one nut (key #2)
on each side.
Your Mantis Edger is now fully assembled!
9
