Mantis SV-5C/2 User Manual

15
Dry Weight . . . . . . .2.8kg — 6 lbs., 3 ounces
Type of Engine . . . .Air Cooled, Two stroke, Single-Cylinder,
Gasoline Engine
Rotation . . . . . . . . . .Clockwise, viewed from TOP
Bore . . . . . . . . . . . . .32.2 mm (1.268 in.)
Stroke . . . . . . . . . . .26.0 mm (1.04 in.)
Spark Plug . . . . . . . .NGK BPM8Y
Fuel . . . . . . . . . . . . .Premixed two stroke fuel
Fuel Oil Ratio . . . . .50:1 ratio with MANTIS oil
Gasoline . . . . . . . . .Unleaded (see page 7)
Displacement . . . . .21.2 cc (1.294 cu. in.)
Exhaust System . . . .Spark arrester muffler
Carburetor . . . . . . . .ZAMA diaphragm model C1U type
Ignition System . . . .Flywheel magneto, capacitor discharge
ignition type
Starter . . . . . . . . . . .Automatic rewind type
Oil . . . . . . . . . . . . . .Designated, two-stroke, air-cooled
engine oil
Fuel Tank Capacity .0.5 lit. (17.0 oz.)
ENGINE SPECIFICATIONS
SERVICE MAINTENANCE GUIDE
* Replacement will be required for commercial use after 600 hours. For Consumer use, cleaning every 6 months is required. Cleaning includes Rebuild Kits.
IMPORTANT: Time Intervals shown are maximum. Actual use and your experience will determine the frequency of required maintenance.
Area Maintenance Frequency
Air Filter Clean
Replace
Daily or every 4 hrs. use
Every 3 mths. or 90 hrs. use
Fuel Filter Inspect
Replace
Monthly
Spark Plug Clean
Replace
Every 3 mths. or 90 hrs. use
6 months or 270 hrs. use
Carburetor Check / Rebuild
Replace
6 months or 300 hrs. use
Yearly or 600 hrs. use*
Cylinder Exhaust Port Inspect / Clean Every 3 mths. or 90 hrs. use
Cooling System Inspect / Clean Before Use
Muffler (Spark Arrestor) Inspect / Clean Monthly
Gear Housing Check Grease Yearly
Tines Inspect / Clean / Lubricate After Use
Fuel Leaks Inspect / Repair Before Use
Fasteners Inspect / Tighten / Replace Before Use
Labels Inspect / Replace Before Use
Handles Inspect / Replace Before Use
Guards / Safety Devices Inspect / Replace Before Use
Fuel Line Inspect / Replace Monthly
Starter Rope Inspect / Replace Monthly
Fuel Strainer Replace Every 3 mths. or 100 hrs. use
Choke Check With each re-fueling
Ignition System Clean
Replace
No maintenance
For coil and flywheel
Notes:
