1918
Control modes
Floor Sensor (active when floor sensor
installed and connected)
Room Sensor with floor limiter (active
when floor sensor installed and
connected)
Room Sensor (active when no floor
sensor is connected)
No Sensor % regulator with cycles
of 20 minutes (active when no floor
sensor is connected)
Working modes
Constant Mode, Event Mode, Boost
Mode
Temperature regulation method
PWM (pulse with modulation method)
with PI control loop
Accuracy – floor/room sensor 0.2°C in the range 0°C to +40°C
Back-up for set values In non-volatile memory
Back-up for time and date
5 years storage or 10 years with 50%
power on
Type of action 1.B. (39)*
Control pollution Degree 2 (49)*
Rated impulse voltage 4kV (75)*
Temperature for the ball pressure test +125°C (77)*
SELV limits realized 22 VDC (86)*
* According to the EN 60730-1 table 1
