Supply voltage
230VAC +/- 10%, 50Hz
Power consumption in sleep mode
400 mW
Power consumption in max. load
1000 mW
Main power switch
2-pole
Relay output
230V, max. 12A
Setpoint range
0ºC to +40ºC
Ambient temperature
- transport
-20ºC to +70ºC
Protection class
IP21
Terminals
2.5mm screw cage clamp
Floor sensor with 3m cable
12k at +25ºC +/- 0.75ºC (no:38165)
Maximum length of oor sensor cable
100m, 2 x 1.5mm (230VAC cable)
Dimension with frame 84 X 84 X 40mm
Color square front RAL 9003
Color switch gear frame RAL 9003
Display
1.8’’ Dot Matrix LCD display (100 x 64
pixels) with blue backlight
Trouble Shooting
In the event of damage or malfunction of one of the temperature sensors,
the heating output cuts off (fail safe) and an error code is displayed.
Number Error Type
E0
Room failure. Mapeheat Thermo Basic is defective. Please
replace the thermostat
E1
Room sensor defective or short circuited. Please replace the
thermostat.
E2
Floor sensor defective or short circuited. Please check or
replace the external sensor*
E5
Internal overheating. Please inspect the installation
*The floor sensor may be replaced by a new one
