Connection for 5.1 Multi-channel Playback
Three MODEL 10 units can be connected by F.C.B.S. and used through linked operation. For details on F.C.B.S. connection, see “Connection
example” (v p. 27).
Connect the outputs of players that have 5.1 channel analog outputs to each of the three units.
If using an active subwoofer, see the instruction manual that came with the subwoofer for further instructions.
Set the IDs for the three amplifiers as explained in How to set ID for F.C.B.S. (v p. 28)
0
When you operate the unit with the ID set to “Leader”, the units set to “Member 1” and “Member 2” are linked.
