Marantz 74 CD7 - Parts List - Mechanical Details; Loader Assembly Detailed Parts; Miscellaneous Mechanical Parts

46
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST, /
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
C309 4822 124 41539 ELECT 47 µF ±20% 16V OA47601620
C310 5322 126 11578 CER. 1000pF ±10% 50V CHIP DK96102300
C311 4822 126 11759 CER. 100pF ±5% 50V CHIP DD95101300
C312 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C314 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C315 4822 126 13309 CER. 0.033µF ±10% CHIP DK96333200
C316 4822 124 81238 TANTL. 0.33µF 35V CHIP EY33403510
C317 4822 124 90357 ELECT 2.2 µF ±20% 50V OA22505020
C318 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C319 4822 126 13837 CER. 0.1 µF ±10% 10V CHIP DK96104200
C320 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C327 4822 124 90363 ELECT 220µF ±20% 10V OA22701020
C328 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C329 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C330 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C331 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C332 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C333 4822 126 11759 CER. 100pF ±5% 50V CHIP DD95101300
C334 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C356 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C357 4822 126 11663 CER. 12pF ±5% 50V CHIP DD95120300
C358 4822 126 11663 CER. 12pF ±5% 50V CHIP DD95120300
C359 5322 126 11578 CER. 1000pF ±10% 50V CHIP DK96102300
C360 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C361 4822 126 11663 CER. 12pF ±5% 50V CHIP DD95120300
C362 4822 126 11663 CER. 12pF ±5% 50V CHIP DD95120300
C363 5322 126 11578 CER. 1000pF ±10% 50V CHIP DK96102300
C364
4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C372
C501
4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C504
C505 4822 124 90363 ELECT 220µF ±20% 10V OA22701020
C506 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C507 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C509 5322 126 11578 CER. 1000pF ±10% 50V CHIP DK96102300
C510 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C511 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C512 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C514 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C515 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C516 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C518 5322 126 11578 CER. 1000pF ±10% 50V CHIP DK96102300
C519 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C520 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C521 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C528 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C529 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C801 4822 124 80582 ELECT4700µF ±20%16V OA47801620
C802 4822 124 22694 ELECT 1000µF 6.3V OA10800620
C803 4822 124 90388 ELECT 3300µF ±20%16V OA33801620
C804 4822 124 90367 ELECT 2200µF 25V OA22802520
C812 4822 124 90367 ELECT 2200µF ±20%25V OA22802520
C813 F 4822 124 22238 ELECT 100µF ±20% 25V OA10702550
C813 K /02 4822 124 80119 ELECT 100µF ±20% 25V OA10702540
C814 F 4822 124 22238 ELECT 100µF ±20% 25V OA10702550
C814 K /02 4822 124 80119 ELECT 100µF ±20% 25V OA10702540
C822 4822 124 90388 ELECT 3300µF ±20%16V OA33801620
C823 4822 124 90364 ELECT 220µF ±20% 16V OA22701620
C851 4822 124 12405 ELECT 4700µF ±20% 35V OB47803520
C852 4822 124 12405 ELECT 4700µF ±20% 35V OB47803520
C855 F 4822 124 22238 ELECT 100µF ±20% 25V OA10702550
C855 K /02 4822 124 80119 ELECT 100µF ±20% 25V OA10702540
C856 F 4822 124 22238 ELECT 100µF ±20% 25V OA10702550
C856 K /02 4822 124 80119 ELECT 100µF ±20% 25V OA10702540
C857 4822 124 22242 ELECT 470µF ±20% 25V OA47702550
C858 4822 124 22242 ELECT 470µF ±20% 25V OA47702550
PP16-RESISTORS CHIP
C321 4822 116 82487 0Ω ±5% 1/16W NN05000610
C355 4822 116 82487 0Ω ±5% 1/16W NN05000610
RN02 4822 117 11977 3.9MΩ ±5% 1/16W NN05395610
RN03 4822 116 83208 18kΩ±5% 1/16W NN05123610
RN04 4822 051 30473 47kΩ ±5% 1/16W NN05473610
RN05 4822 051 30103 10kΩ ±5% 1/16W NN05103610
RN08 4822 051 30472 4.7kΩ ±5% 1/16W NN05472610
RN10 4822 051 30472 4.7kΩ±5% 1/16W NN05472610
RN13 4822 051 30223 22kΩ ±5% 1/16W NN05223610
RN14 4822 051 30103 10kΩ ±5% 1/16W NN05103610
RN15 4822 051 30472 4.7kΩ ±5% 1/16W NN05472610
RN16 4822 051 30472 4.7kΩ ±5% 1/16W NN05472610
RN21 4822 051 30103 10kΩ ±5% 1/16W NN05103610
RN22 4822 051 30104 100kΩ ±5% 1/16W NN05104610
RN23 4822 051 30332 3.3kΩ ±5% 1/16W NN05332610
RN24 4822 051 30473 47kΩ ±5% 1/16W NN05473610
RN25 4822 051 30333 33kΩ ±5% 1/16W NN05333610
RN26 4822 051 30104 100kΩ ±5% 1/16W NN05104610
RN27 4822 051 30332 3.3kΩ ±5% 1/16W NN05332610
RT01 4822 051 30101 100Ω ±5% 1/16W NN05101610
RT02 4822 051 30339 33Ω ±5% 1/16W NN05330610
RT03 4822 051 30759 75Ω ±5% 1/16W NN05750610
RT04 4822 051 30339 33Ω ±5% 1/16W NN05330610
RT05 4822 051 30759 75Ω±5% 1/16W NN05750610
RY41 4822 051 30103 10kΩ±5% 1/16W NN05103610
RY42 4822 051 30103 10kΩ ±5% 1/16W NN05103610
RY51 4822 051 30223 22kΩ ±5% 1/16W NN05223610
RY52 4822 051 30472 4.7kΩ ±5% 1/16W NN05472610
RY53 4822 051 30473 47kΩ ±5% 1/16W NN05473610
RY54 4822 051 30473 47kΩ ±5% 1/16W NN05473610
RY55 4822 051 30473 47kΩ ±5% 1/16W NN05473610
RY56 4822 051 30103 10kΩ ±5% 1/16W NN05103610
RY61 4822 116 83255 3.3kΩ ±1% 1/10W NI01332110
R301 4822 051 30759 75Ω ±5% 1/16W NN05750610
R302 4822 051 30759 75Ω±5% 1/16W NN05750610
R303 4822 051 30102 1kΩ ±5% 1/16W NN05102610
R305 4822 051 30473 47kΩ ±5% 1/16W NN05473610
R307 4822 051 30222 2.2kΩ±5% 1/16W NN05222610
R308 4822 051 30223 22kΩ ±5% 1/16W NN05223610
R309 4822 051 30223 22kΩ ±5% 1/16W NN05223610
R310 4822 051 30103 10kΩ ±5% 1/16W NN05103610
R311 4822 051 30471 470Ω ±5% 1/16W NN05471610
R314 4822 051 30101 100Ω ±5% 1/16W NN05101610
R315 4822 051 30472 4.7kΩ±5% 1/16W NN05472610
R316 4822 051 30223 22kΩ ±5% 1/16W NN05223610
R317 4822 051 30223 22kΩ±5% 1/16W NN05223610
R318 4822 051 30223 22kΩ ±5% 1/16W NN05223610
R319 4822 051 30223 22kΩ±5% 1/16W NN05223610
R320 4822 051 30479 47Ω ±5% 1/16W NN05470610
R321 4822 051 30479 47Ω ±5% 1/16W NN05470610
R322 4822 051 30479 47Ω±5% 1/16W NN05470610
R323 4822 051 30479 47Ω ±5% 1/16W NN05470610
R324 4822 051 30101 100Ω ±5% 1/16W NN05101610
R325 4822 051 30101 100Ω ±5% 1/16W NN05101610
R326 4822 051 30101 100Ω ±5% 1/16W NN05101610
R327 4822 051 30101 100Ω ±5% 1/16W NN05101610
R330 4822 051 30103 10kΩ ±5% 1/16W NN05103610
R331 4822 051 30334 330kΩ ±5% 1/16W NN05334610
R332 4822 051 30223 22kΩ ±5% 1/16W NN05223610
R333 4822 051 30223 22kΩ±5% 1/16W NN05223610
R334 4822 051 30223 22kΩ ±5% 1/16W NN05223610
R335 4822 051 30471 470Ω ±5% 1/16W NN05471610
R336 4822 051 30471 470Ω ±5% 1/16W NN05471610
R338 4822 051 30223 22kΩ±5% 1/16W NN05223610
