POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST, /
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
R339 4822 051 30223 22kΩ ±5% 1/16W NN05223610
R340 4822 051 30223 22kΩ ±5% 1/16W NN05223610
R341 4822 051 30334 330kΩ ±5% 1/16W NN05334610
R342 4822 117 12968 820Ω ±5% 1/16W NN05821610
R343 4822 051 30101 100Ω ±5% 1/16W NN05101610
R344 4822 051 30334 330kΩ±5% 1/16W NN05334610
R345 4822 117 12968 820Ω±5% 1/16W NN05821610
R346 4822 051 30101 100Ω ±5% 1/16W NN05101610
R348 4822 051 30101 100Ω ±5% 1/16W NN05101610
R349 4822 051 30101 100Ω±5% 1/16W NN05101610
R350 4822 051 30479 47Ω ±5% 1/16W NN05470610
R351 4822 051 30479 47Ω ±5% 1/16W NN05470610
R501 4822 051 30223 22kΩ±5% 1/16W NN05223610
R502 4822 051 30223 22kΩ±5% 1/16W NN05223610
R503 4822 051 30223 22kΩ ±5% 1/16W NN05223610
R504 4822 051 30223 22kΩ ±5% 1/16W NN05223610
R505 4822 051 30223 22kΩ ±5% 1/16W NN05223610
R506 4822 051 30103 10kΩ ±5% 1/16W NN05103610
R507 4822 051 30104 100kΩ ±5% 1/16W NN05104610
R508 4822 051 30104 100kΩ ±5% 1/16W NN05104610
R509 4822 051 30104 100kΩ ±5% 1/16W NN05104610
R510 4822 051 30104 100kΩ ±5% 1/16W NN05104610
R511 4822 051 30104 100kΩ ±5% 1/16W NN05104610
R512 4822 051 30223 22kΩ ±5% 1/16W NN05223610
R513 4822 051 30103 10kΩ ±5% 1/16W NN05103610
R514 4822 051 30104 100kΩ ±5% 1/16W NN05104610
R515 4822 051 30104 100kΩ ±5% 1/16W NN05104610
R516 4822 051 30104 100kΩ ±5% 1/16W NN05104610
R517 4822 051 30104 100kΩ ±5% 1/16W NN05104610
R518 4822 051 30104 100kΩ ±5% 1/16W NN05104610
R520 4822 051 30103 10kΩ ±5% 1/16W NN05103610
R527 4822 116 82487 0Ω ±5% 1/16W NN05000610
R529 4822 051 30103 10kΩ ±5% 1/16W NN05103610
R530 4822 051 30471 470Ω ±5% 1/16W NN05471610
R531 4822 051 30471 470Ω ±5% 1/16W NN05471610
R532 4822 051 30471 470Ω ±5% 1/16W NN05471610
R861 /02 390Ω ±5% 2W NON CHIP GA05391020
R862 /02 390Ω ±5% 2W NON CHIP GA05391020
PP16-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RD01 RN01 RN06
RY57 RY58 R813-R816
R851-R858
PP16-SEMICONDUCTORS
DN01
4822 130 80839 DIODE S5688G 1A VRM=400V HD20029050
DN05
DN09 4822 130 33948 ZENER DIODE
RD5.6JB2 MTZJ5.6B
HD30561000
DN10 4822 130 32362 DIODE 1SS176 MA165
1SS254 30V 0.1A
HD20002000
DN11 4822 130 32362 DIODE 1SS176 MA165
1SS254 30V 0.1A
HD20002000
DN15 4822 130 32362 DIODE 1SS176 MA165
1SS254 30V 0.1A
HD20002000
DY11 4822 130 10667 ZENER DIODE
RD4.7JB2 MTZJ4.7B
HD30471000
DY51 4822 130 32362 DIODE 1SS176 MA165
1SS254 30V 0.1A
HD20002000
DY61
4822 130 80839 DIODE S5688G 1A VRM=400V HD20029050
DY64
DY65 4822 130 80116 ZENER DIODE
RD24JB2 MTZJ24D
HD32401000
DY66 4822 130 32362 DIODE 1SS176 MA165
1SS254 30V 0.1A
HD20002000
D301 4822 130 83715 CHIP DIODE DAN202U HZ21005000
D801
4822 130 80839 DIODE S5688G 1A VRM=400V HD20029050
D808
D811
4822 130 80839 DIODE S5688G 1A VRM=400V HD20029050
D814
D815 4822 130 80318 ZENER DIODE
RD6.8JB2 MTZJ6.8C
HD30681000
D821
4822 130 80839 DIODE S5688G 1A VRM=400V HD20029050
D824
D851
4822 130 82422 DIODE EK16LF VRM60V HD20041080
D854
D856 4822 130 33948 ZENER DIODE
RD5.6JB2 MTZJ5.6B
HD30561000
D857 4822 130 33948 ZENER DIODE
RD5.6JB2 MTZJ5.6B
HD30561000
QN01 4822 130 61355 CHIP TRS. 2SC2712 0 Y HX327122A0
QN02 4822 130 61355 CHIP TRS. 2SC2712 0 Y HX327122A0
QN03 4822 130 11507 DIG.TRS. UMH4N BA20070210
QN04 4822 130 61355 CHIP TRS. 2SC2712 0 Y HX327122A0
QN05 4822 130 61311 CHIP TRS. 2SA1162 O Y HX111622A0
QN13 4822 130 61355 CHIP TRS. 2SC2712 O Y HX327122A0
QN21 4822 209 83312 IC TA7317P HC10042050
QT01 4822 209 31423 IC TC7W04F HC700405W0
QY11 4822 111 92195 DIG.TRS. HN1A01F Y GR BA10011050
QY12 4822 130 60839 TRS. 2SC2458 Y GR HT324582B0
QY41 4822 130 63844 DIG.TRS. HN1C03FPNx2 BA20016050
QY51 4822 130 61355 CHIP TRS. 2SC2712 0 Y HX327122A0
QY61 4822 130 42734 CHIP TRS. 2SB798 DL DK HX207982A0
Q301 4822 209 32984 IC TC7SHU04F HC10427050
Q302 4822 209 90597 IC TCW125FU HC10409050
Q303 4822 130 61355 CHIP TRS. 2SC2712 0 Y HX327122A0
Q304 4822 209 33578 IC TDA1315 HC10117490
Q305 4822 130 61355 CHIP TRS. 2SC2712 0 Y HX327122A0
Q306 4822 130 61355 CHIP TRS. 2SC2712 0 Y HX327122A0
Q308 4822 130 61311 CHIP TRS. 2SA1162 0 Y HX111622A0
Q309 4822 209 17427 IC SM5844AF HC10013350
Q311 4822 209 61494 IC 74HC74 FLAT HC707400Z0
Q312 4822 209 31423 IC TC7W04F HC700405W0
Q313 4822 209 33581 IC TC7W08F HC10392050
Q314 4822 209 90597 IC TCW125FU HC10409050
Q315 4822 209 17428 IC 74HC165 FLAT HC716500R0
Q316 4822 209 30426 IC 74HC00 FLAT HC700000Z0
Q317 4822 209 15997 IC TC74HC393AF HC739305R0
Q318 4822 209 17429 IC 74HC107 FLAT HC710700R0
Q319 4822 209 61494 IC 74HC74 FLAT HC707400Z0
Q320 4822 209 62764 IC 74HC164 FLAT HC716400Z0
Q321 4822 209 15997 IC TC74HC393AF COUNTER HC739305R0
Q322 4822 209 32984 IC TC7SHU04F HC10427050
Q323 4822 209 32984 IC TC7SHU04F HC10427050
Q324 4822 209 90597 IC TCW125FU HC10409050
Q325 4822 209 32984 IC TC7SHU04F HC10427050
Q326 4822 209 91176 IC 74HC257AF HC725705R0
Q327 4822 209 90597 IC TCW125FU HC10409050
Q328 4822 209 17431 IC 74HC393 FLAT HC739300R0
Q329 4822 130 61311 CHIP TRS. 2SA1162 O Y HX111622A0
Q330 4822 209 61494 IC 74HC74 FLAT HC707400Z0
Q331 4822 209 32984 IC TC7SHU04F HC10427050
Q332 4822 130 61355 CHIP TRS. 2SC2712 O Y HX327122A0
Q333 4822 130 61355 CHIP TRS. 2SC2712 O Y HX327122A0
Q501 4822 209 17432 IC 74HC595 HC759500R0
Q502 4822 209 17432 IC 74HC595 HC759500R0
