Marantz 74 CD7 - Page 32

48
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST, /
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
Q503 4822 209 17432 IC 74HC595 HC759500R0
Q504 4822 209 30426 IC CMOS 74HC00 HC700000Z0
Q505 4822 130 11507 DIG.TRS. UMH4N BA20070210
Q506 F 4822 209 17433 EPROM/EEPROM
256K BYT PKG.355K506N1
HJ355KZ200
Q507 4822 209 17434 IC DSP56004 HC10103170
Q508 F EPROM/EEPROM
512 BYT PRG.355K508-1
HJ355KZ100
Q508 K /02 4822 209 17435 EPROM/EEPROM
512K BYT PRG.355K508N1
HJ355KZ300
Q509 4822 209 17434 IC DSP56004 HC10103170
Q510 4822 130 61355 CHIP TRS. 2SC2712 O Y HX327122A0
Q512 4822 209 31423 IC TC7W04F HC700405W0
Q513 4822 209 33581 IC TC7W08F HC10392050
Q520 4822 130 61355 CHIP TRS. 2SC2712 O Y HX327122A0
Q801 4822 209 17436 IC BA05T 5V/1A TO220 HC36905210
Q802 4822 209 17436 IC BA05T 5V/1A TO220 HC36905210
Q811 4822 130 42836 F.E.T. 2SK246 GR HF202461C0
Q812 4822 130 42949 TRS. 2SA970 GR BL HT109702A0
Q813 4822 130 10176 F.E.T. 2SJ313 O Y HF10313100
Q821 4822 209 17437 IC PQ09RF1 HC31909320
Q851 4822 130 42836 F.E.T. 2SK246 GR HF202461C0
Q852 4822 130 11605 TRS. 2SD1415A HT41415100
Q853 4822 130 43233 TRS. 2SC2240 GR BL HT322402A0
Q855 4822 130 42836 F.E.T. 2SK246 GR HF202461C0
Q856 4822 130 11604 TRS. 2SB1020A HT21020100
Q857 4822 130 42949 TRS. 2SA970 GR BL HT109702A0
PP16-MISCELLANEOUS
F801 F FUSE 1.6A 250V UL FS10160350
F801 K /02 4822 070 31002 FUSE 1A 250V BS LISTED FS10100850
F811 F FUSE 1A 250V UL FS10100350
F811 K /02 4822 070 38001 FUSE 800MA 250V BS LISTED FS10080850
F821 F FUSE 1A 250V UL FS10100350
F821 K /02 4822 070 38001 FUSE 800MA 250V BS LISTED FS10080850
F851 F FUSE 1A 250V UL FS10100350
F851 K /02 4822 070 38001 FUSE 800MA 250V BS LISTED FS10080850
F852 F FUSE 1A 250V UL FS10100350
F852 K /02 4822 070 38001 FUSE 800MA 250V BS LISTED FS10080850
G801 4822 121 20263 NOISE KILLER 0.47µF+6.8Ω BF47400010
G810 F 4822 121 20263 NOISE KILLER 0.47µF+6.8Ω BF47400010
G850 4822 121 20263 NOISE KILLER 0.47µF+6.8Ω BF47400010
JT01 4822 265 11582 TERMINAL 1P RCA PIN JACK YT02011000
JT02 4822 265 11582 TERMINAL 1P RCA PIN JACK YT02011000
JT03 4822 267 31369 OPT. CONNECTOR GP1F32T
OPTICAL OUT
YJ15000090
J301 4822 265 11582 TERMINAL 1P RCA PIN JACK YT02011000
J302 4822 265 11582 TERMINAL 1P RCA PIN JACK YT02011000
J303 4822 218 11487 OPT. CONNECTOR GP1F32R
OPTICAL RECEIVER
YJ15000150
LT01 4822 142 60422 PULSE TRANSF.
TPS247MN-0386AN
TP41042030
LT02 4822 142 60422 PULSE TRANSF.
TPS247MN-0386AN
TP41042030
LT04 4822 158 60654 CHIP INDUCTOR BLM31A02 FC90030070
LY51 4822 280 10353 RELAY DC9V NA-9-WK LY20090090
L301 4822 158 60654 CHIP INDUCTOR BLM31A02 FC90030070
L302 4822 158 60654 CHIP INDUCTOR BLM31A02 FC90030070
L304 4822 157 11192 CHIP INDUCTANCE 3.3 UH
NL322522
LU12332010
L305 4822 157 11192 CHIP INDUCTANCE 3.3 UH
NL322522
LU12332010
L306 4822 158 60654 FERRITE CORE BLM31A02
CHIP INDUCTOR
FC90030070
S301 4822 277 21559 SLIDE SW. COAX OPT SEL SS02021150
S302 4822 277 21559 SLIDE SW. INPUT FORMAT SS02021150
X301 4822 242 10818 CRYSTAL 33.8688MHz JX33001380
X302 4822 242 11032 CRYSTAL 36.864MHz JX36001380
PV16-SERVO/DEC/MOTOR
CIRCUIT BOARD
PV16-CAPACITORS
CF02 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CF05 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CF06 4822 124 41539 ELECT 47µF ±20% 16V OA47601620
CF07 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CF11 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CF12 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CF13 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CF15 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CF16 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CM01
4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CM04
C100
4822 126 11682 CER. 220pF ±10% CHIP DK96221300
C105
C106 4822 126 13837 CER. 0.1 µF ±10% 10V CHIP DK96104200
C108 4822 122 33777 CER. 47pF ±5% 50V CHIP DD95470300
C109 4822 126 11567 CER. 0.022µF ±10% 16V CHIP DK96223200
C110 4822 126 12495 CER. 1500pF ±10% CHIP DK96152300
C111 4822 126 14249 CER. 560pF ±10% CHIP DK96561300
C112 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C113 4822 126 11759 CER. 100pF ±5% 50V CHIP DD95101300
C119 4822 126 11567 CER. 0.022µF ±10% 16V CHIP DK96223200
C132 4822 126 14581 CER. 0.015µF ±10% 16V CHIP DK96153200
C133 4822 126 11695 CER. 330pF ±5% 50V CHIP DD95331300
C134 4822 126 11563 CER. 180pF ±5% CHIP DD95181300
C135 4822 126 11567 CER. 0.022µF ±10% 16V CHIP DK96223200
C136 4822 124 41539 ELECT 47µF ±20% 16V OA47601620
C139 4822 124 11131 ELECT 47µF 6.3V CHIP EY47600620
C140
4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C145
C146 4822 124 11131 ELECT 47µF 6.3V CHIP EY47600620
C147 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C148 4822 124 22694 ELECT 1000µF ±20% 6.3V OA10800620
C149 4822 124 41539 ELECT 47 µF ±20% 16V OA47601620
C151 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C152 4822 124 41539 ELECT 47 µF ±20% 16V OA47601620
C153 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C154 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C155 4822 124 22277 ELECT 470µF ±20% 16V OA47701620
C156 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C165 4822 122 33788 CER. 82pF±5% CHIP DD95820300
C166 4822 126 12495 CER. 1500pF ±10% CHIP DK96152300
C221 4822 126 13267 CER. 330pF ±10% CHIP DK96331300
C222 4822 126 12846 CER. 0.012µF ±10% CHIP DK96123200
C223 4822 126 11568 CER. 470pF ±10% CHIP DK96471300
C224 4822 126 11685 CER. 4700pF ±10% 50V CHIP DK96472300
C225 4822 126 13837 CER. 0.1µF ±10% 10V CHIP DK96104200
C226 5322 126 11578 CER. 1000pF ±10% 50V CHIP DK96102300
C227 4822 126 13837 CER. 0.1 µF ±10% 10V CHIP DK96104200
C228 4822 126 13837 CER. 0.1 µF ±10% 10V CHIP DK96104200
C229 5322 126 11578 CER. 1000pF ±10% 50V CHIP DK96102300
PV16-RESISTORS CHIP
RF09 4822 051 30105 1MΩ ±5% 1/16W NN05105610
RF10 4822 051 30474 470kΩ ±5% 1/16W NN05474610
RF11 4822 051 30223 22kΩ ±5% 1/16W NN05223610
