49
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST, /
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
RF14
4822 051 30223 22kΩ ±5% 1/16W NN05223610
RF17
RF18
4822 051 30472 4.7kΩ ±5% 1/16W NN05472610
RF21
RF22 4822 051 30223 22kΩ ±5% 1/16W NN05223610
RF23 4822 051 30223 22kΩ ±5% 1/16W NN05223610
RF25
4822 051 30223 22kΩ ±5% 1/16W NN05223610
RF35
RM01 4822 051 30472 4.7kΩ ±5% 1/16W NN05472610
RM02 4822 051 30472 4.7kΩ ±5% 1/16W NN05472610
RM03 4822 051 30222 2.2kΩ ±5% 1/16W NN05222610
RM04 4822 051 30222 2.2kΩ ±5% 1/16W NN05222610
RM05 4822 051 30472 4.7kΩ ±5% 1/16W NN05472610
RM06 4822 051 30472 4.7kΩ ±5% 1/16W NN05472610
RM07 4822 051 30222 2.2kΩ ±5% 1/16W NN05222610
RM08 4822 051 30222 2.2kΩ ±5% 1/16W NN05222610
R100 4822 051 30103 10kΩ ±5% 1/16W NN05103610
R101 4822 051 30103 10kΩ ±5% 1/16W NN05103610
R102 4822 051 30274 270kΩ ±5% 1/16W NN05274610
R103 4822 051 30223 22kΩ ±5% 1/16W NN05223610
R104 4822 116 82487 0Ω±5% 1/16W NN05000610
R105 4822 051 30104 100kΩ±5% 1/16W NN05104610
R106 4822 116 83208 12kΩ ±5% 1/16W NN05123610
R107 4822 116 83208 12kΩ ±5% 1/16W NN05123610
R109 4822 051 30681 680Ω ±5% 1/16W NN05681610
R110 4822 116 83208 12kΩ ±5% 1/16W NN05123610
R111 4822 051 30103 10kΩ ±5% 1/16W NN05103610
R113 4822 116 83207 1.2kΩ±5% 1/16W NN05122610
R116 4822 051 30223 22kΩ ±5% 1/16W NN05223610
R117 4822 117 12968 820Ω ±5% 1/16W NN05821610
R119 4822 051 30333 33kΩ±5% 1/16W NN05333610
R120 4822 051 30333 33kΩ ±5% 1/16W NN05333610
R121 4822 116 83211 1.8kΩ±5% 1/16W NN05182610
R123 4822 116 83213 270Ω ±5% 1/16W NN05271610
R124 4822 116 83213 270Ω ±5% 1/16W NN05271610
R125
4822 051 30103 10kΩ ±5% 1/16W NN05103610
R128
R129 4822 051 30101 100Ω ±5% 1/16W NN05101610
R133 4822 051 30392 3.9kΩ ±5% 1/16W NN05392610
R134 4822 051 30472 4.7kΩ ±5% 1/16W NN05472610
R135 4822 051 30471 470Ω ±5% 1/16W NN05471610
R136 4822 051 30471 470Ω ±5% 1/16W NN05471610
R137 4822 051 30272 2.7kΩ ±5% 1/16W NN05272610
R138 4822 051 30272 2.7kΩ ±5% 1/16W NN05272610
R139 4822 051 30103 10kΩ ±5% 1/16W NN05103610
R140 4822 116 83339 56Ω ±5% 1/16W NN05560610
R141 4822 051 30479 47Ω±5% 1/16W NN05470610
R142 4822 051 30391 390Ω ±5% 1/16W NN05391610
R143 4822 116 60309 2.2Ω ±5% 1/4W FUSIBLE NH05022140
R144 4822 051 30102 1kΩ ±5% 1/16W NN05102610
R145 4822 051 30222 2.2kΩ ±5% 1/16W NN05222610
R146 4822 051 30103 10kΩ ±5% 1/16W NN05103610
R147 4822 051 30472 4.7kΩ ±5% 1/16W NN05472610
R148 4822 116 60309 2.2Ω ±5% 1/4W FUSIBLE NH05022140
R151
4822 051 30223 22kΩ ±5% 1/16W NN05223610
R157
R158 4822 051 30104 100kΩ ±5% 1/16W NN05104610
R160 4822 051 30104 100kΩ ±5% 1/16W NN05104610
R161
4822 051 30101 100Ω ±5% 1/16W NN05101610
R164
R165 4822 051 30223 22kΩ ±5% 1/16W NN05223610
R166 4822 051 30332 3.3kΩ ±5% 1/16W NN05332610
PV16-SEMICONDUCTORS
QF01 4822 209 17438 ONE TIME PROM
µPD78P078 1-TIME µ-COM
HS355KN000
QF02 4822 209 15921 IC ET S-806D-Z HC10077530
QF03 4822 209 17428 IC 74HC165 FLAT HC716500R0
QF04 4822 209 17428 IC 74HC165 FLAT HC716500R0
QF05 4822 209 17428 IC 74HC165 FLAT HC716500R0
QF06 4822 209 17432 IC 74HC595 HC759500R0
QF07 4822 209 62764 IC 74HC164F HC716400Z0
QF08 4822 209 32984 IC TC7SHU04F HC10427050
QF09 4822 209 90597 IC TCW125FU HC10409050
QM01 4822 130 43954 CHIP TRS. 2SD999 DL DK HX409992A0
QM02 4822 130 43954 CHIP TRS. 2SD999 DL DK HX409992A0
QM03 4822 130 42734 CHIP TRS. 2SB798 DL DK HX207982A0
QM04 4822 130 42734 CHIP TRS. 2SB798 DL DK HX207982A0
QM05 4822 130 43954 CHIP TRS. 2SD999 DL DK HX409992A0
QM06 4822 130 43954 CHIP TRS. 2SD999 DL DK HX409992A0
QM07 4822 130 42734 CHIP TRS. 2SB798 DL DK HX207982A0
QM08 4822 130 42734 CHIP TRS. 2SB798 DL DK HX207982A0
QM09
4822 130 61355 CHIP TRS. 2SC2712 0 Y HX327122A0
QM12
Q102 4822 209 91174 IC SAA7372GP HC10132490
Q103 4822 209 16372 IC TDA7073AT HC10165490
Q104 4822 209 16372 IC TDA7073AT HC10165490
Q107 4822 130 61355 CHIP TRS. 2SC2712 0 Y HX327122A0
Q108 4822 130 61311 CHIP TRS. 2SA1162 O Y HX111622A0
Q109 4822 130 61355 CHIP TRS. 2SC2712 0 Y HX327122A0
Q110 4822 130 61311 CHIP TRS. 2SA1162 O Y HX111622A0
Q111 4822 130 61355 CHIP TRS. 2SC2712 O Y HX327122A0
Q112 4822 130 61355 CHIP TRS. 2SC2712 0 Y HX327122A0
PV16-MISCELLANEOUS
L103
4822 158 60654 CHIP INDUCTOR BLM31A02 FC90030070
L106
XF01 4822 242 10992 CERAMIC RESONATOR
CSTCC5.00MG-TC 5MHz
FQ05004040
PY16-FRONT FL/IR/KEY
CIRCUIT BOARD
PY16-CAPACITORS
CY16 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CY17 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CY20 4822 124 21901 ELECT 47µF 6.3V EJ47600610
CY51 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
PY16-RESISTORS CHIP
RY01 4822 051 30472 4.7kΩ ±5% 1/16W NN05472610
RY03 4822 051 30222 2.2kΩ ±5% 1/16W NN05222610
RY04 4822 051 30222 2.2kΩ ±5% 1/16W NN05222610
RY05 4822 051 30682 6.8kΩ ±5% 1/16W NN05682610
RY06 4822 051 30472 4.7kΩ ±5% 1/16W NN05472610
RY07 4822 051 30222 2.2kΩ ±5% 1/16W NN05222610
RY08 4822 051 30222 2.2kΩ ±5% 1/16W NN05222610
RY09 4822 051 30682 6.8kΩ ±5% 1/16W NN05682610
RY10 4822 051 30472 4.7kΩ ±5% 1/16W NN05472610
PY16-MISCELLANEOUS
SY01
4822 276 13537 PUSH SW. SKHVBF 260GF SP01012030
SY06
