Marantz AMP10 - Connecting a Preamplifier

Connecting a Preamplifier
Example of connections to Marantz AV 10 Preamplifier
o
Connecting the UNBALANCED RCA PRE OUT connector
If using the UNBALANCED RCA connectors, switch the RCA/XLR INPUT selector setting to “RCA”. Set the NORMAL/BI-AMP/BTL selector to
“NORMAL”.
NOTE
0
Be sure to configure the RCA/XLR INPUT selector and
NORMAL/BI-AMP/BTL selector settings before turning the
power on. If you try to change these settings after turning
the power on, the settings will not change.
Marantz
AV10
Marantz
AV10
SR SLFR FL C RHR RHL TMR TML CH TSFHR FHLFWR FWL
SBLSBR
