7. SERVICE PROGRAM
REMARK
If these service programs are set, All user preset memories will be cleared.
1. Tracking point memory mode
This service program can be use for measurement of the tuner circuit.
When the product is POWER ON, press 3 buttons [ PRESET▲+ PRESET▼+ MEMO ] simultaneously over 3 seconds.
FLD shows “FACTORY” for approx. 3 seconds. Frequencies to be memorized are as follows.
VERSION P1 P2 P3 P4
FM U 90.0 98.0 106.0 87.5
SCAN STEP P5 P6 P7 P8 P9
P12
10 kHz 600.0 1000.0 1400.0 520.0
How to stop the tracking point memory mode :
Press the POWER button. FLD shows “DEFAULT”, then all memories are cleared. And the product will be STAND-BY
status.
2. FLD segment check mode
This service program is available for all luminous segments by the following steps.
When the product is POWER ON, press 3 buttons [ TUNING ▲+ TUNING ▼ + MEMO ] simultaneously over 3 seconds.
FLD shows “SERVICE” for approx. 3 seconds.
1. All segments light up for 5 seconds.
2. Each segment lights up step by step.
3. 1. and 2. will be repeated.
How to stop the FLD segment check mode :
Press 3 buttons [ TUNING ▲+ TUNING ▼ + MEMO ] simultaneously again or Press the POWER button.
3. Version of microprocessor (CPU)
This program is available to confirm the version of each CPU by the following steps.
QU01 : When the product is POWER ON, press 3 buttons [ TUNING ▼+ MEMO + CLEAR ] simultaneously.
FLD shows version of Program code (QU01:Main CPU) for 5 seconds.
Q691 : When the product is the tracking point memory mode (Refer to the above “1. Tracking point memory mode”), then
press 2 buttons [ CLEAR + TUNING ▼ ] simultaneously.
FLD shows version of Program code (Q691:Sub CPU) for 5 seconds.
4. Frequency response for all channels outputs.
This program is available to confirm Cross Over circuit for SPK setup as follows.
Same signal is output from all channel, even though input is Digital or Analog.
Input signal should be L+R signal (L=R ).
When the product is the tracking point memory mode (Refer to the above “1. Tracking point memory mode”), then press
2 buttons [ CLEAR + PRESET▲ ] simultaneously.
FLD shows “FILTER”
The filter mode is changed by pressing 2 buttons [ CLEAR + PRESET▲ ] simultaneously.
FLD shows "FILTER1”
“FILTER2” “FILTER3” “FILTER1” by pressing them.
Input signals are selectable (Digital or Analog Inputs).
Same signal will be output from all channels. (Except sub woofer)
(Notes : The signal is processed by P604 on this mode)
AM
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
001B FRONT PANEL 280J248030
002B 482245911172 BADGE 185J251010
003B LENS IR 280J355010
004B 482238111564 LENS POWER/STANDBY 194J355130
005B WINDOW 280J158010
010B 482241062744 BUTTON POWER 285K270010
011B 482240421012 JOINT POWER SW LINK 025J125010
012B 482241341495 KNOB TONE 042J154020
013B 482241010643 KNOB MAIN VOL. 261J154010
015B CHASSIS MOLD FRONT 280J105010
016B BUTTON MODE SELECTOR 280J270210
017B BUTTON PRESET 280J270020
020B 482225692097 HOLDER FL 183J271020
021B 482245910942 STICKER ADHESIVE 056J122020
002G 482246242045 LEG FRONT 183J057010
003G 482246242048 LEG REAR 183J057110
907G U 482253260948 BUSHING MAINS CORD 450H259010
L001 MAINS TRANSF. FOR U TS16031070
L002 FERRITE CORE SSC-40-12 FC90400010
WE01 4822 321 23702 JUMPER LEAD J501-JS06
SMCD-23X130 P1.25
YU23130500
WL01 JUMPER LEAD JL03-JS07
SMCD-15X200 P1.25
YU15200500
WS01 4822 321 62312 JUMPER LEAD JU01-JG03
SMCD-33X200 P1.25
YU33200510
W001 MAINS CORD UL CSA SPT-2 YC02000880
PACKING
001T U USER GUIDE FOR AV560U 316J851250
Z001 REMOTE COMMANDER
RC-18SR
ZK300J0010
NOT STANDRD SPARE
PARTS
001S PACKING CASE 316J801010
002S CUSHION (LEFT) 280J809010
003S CUSHION (RIGHT) 280J809020
Z003 4822 303 30314 EXT.ANTENNA FM EXT ANT ZA02000070
Z004 4822 157 63083 ANT. COIL
LA-700HB LOOP ANT.
LA00055010
Z005 4822 264 30265 PLUG ANT ADAPTOR YP90000310
Z006 4822 321 21438 CONNECTIVE CORD
RCA ST.CORD 1M
ZD01000330
