43
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
P604-AUDIO FUNCTION DSP
CIRCUIT BOARD
P604-CAPACITORS
CC01 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CC02 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CC09
4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CC13
CC14 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CC15 4822 122 33761 CER. 22pF ±5% CG 50V DD95220300
CC16 4822 122 33761 CER. 22pF ±5% CG 50V DD95220300
CC17 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CC18 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CC25 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CC26 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CC27 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CC28 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CC29 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CC30 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CC33 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CC34 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CC35 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CC36 4822 122 33761 CER. 22pF ±5% CG 50V DD95220300
CC38 4822 122 33761 CER. 22pF ±5% CG 50V DD95220300
CC39 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CC40 4822 122 33741 CER. 10pF ±0.5pF 50V DD91100300
CC41 4822 052 10101 RES. 100Ω ±5% 1/6W GG05101160
CC43 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CC47 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CC50 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CC51 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CC52
4822 126 11687 CER. 0.1µF +80%-20% DK98104200
CC60
CC61 4822 124 41535 ELECT. 100µF 25V M RA-2 OA10702520
CC62 4822 124 41535 ELECT. 100µF 25V M RA-2 OA10702520
CC63
4822 126 11687 CER. 0.1µF +80%-20% DK98104200
CC68
CC69 4822 126 11759 CER. 100pF ±5% CG 50V DD95101300
CC70 4822 126 11759 CER. 100pF ±5% CG 50V DD95101300
CC71 4822 126 11759 CER. 100pF ±5% CG 50V DD95101300
CC72 4822 126 11687 CER. 0.1µF +80%-20% DK98104200
CC73 4822 124 90354 ELECT. 100µF 16V M RA-2 OA10701620
CC74 4822 124 90354 ELECT. 100µF 16V M RA-2 OA10701620
CC75
4822 126 11687 CER. 0.1µF +80%-20% DK98104200
CC82
CC83 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CC84 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CC85 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CD01 4822 124 90353 ELECT. 100µF 10V M RA-2 OA10701020
CD02 4822 126 11687 CER. 0.1µF +80%-20% DK98104200
CD03 4822 124 90353 ELECT. 100µF 10V M RA-2 OA10701020
CD04 4822 126 11687 CER. 0.1µF +80%-20% DK98104200
CD05 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CD06 4822 126 11687 CER. 0.1µF +80%-20% DK98104200
CD07 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CD08 4822 126 11687 CER. 0.1µF +80%-20% DK98104200
CD09 4822 124 90353 ELECT. 100µF 10V M RA-2 OA10701020
CD10 4822 157 10884 EMI FILTER BLM11A221S FN31000010
CD51
4822 126 11703 CER. 0.01µF +80%-20% DK98103300
CD59
CD60 4822 124 90353 ELECT. 100µF 10V M RA-2 OA10701020
CD61
4822 126 11703 CER. 0.01µF +80%-20% DK98103300
CD66
CD68 4822 126 11703 CER. 0.01µF +80%-20% DK98103300
CD69 4822 126 11703 CER. 0.01µF +80%-20% DK98103300
CD70
4822 124 41535 ELECT. 100µF 25V M RA-2 OA10702520
CD74
CD76 4822 124 90353 ELECT. 100µF 10V M RA-2 OA10701020
CD77 4822 124 90353 ELECT. 100µF 10V M RA-2 OA10701020
CG01 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CG02 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CG03 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CG04 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CG05 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CG06 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CG07 4822 122 33761 CER. 22pF ±5% CG 50V DD95220300
CG08 4822 122 33761 CER. 22pF ±5% CG 50V DD95220300
CG13 4822 122 33777 CER. 47pF ±5% CG 50V DD95470300
CG14 4822 122 33777 CER. 47pF ±5% CG 50V DD95470300
CG15
4822 126 11759 CER. 100pF ±5% CG 50V DD95101300
CG18
CG19 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CG20 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CG21 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CG22 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CG23 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CG24 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CG25
4822 126 11759 CER. 100pF ±5% CG 50V DD95101300
CG30
CG31
4822 122 40617 CER. 0.1µF +80%-20% 50V DD38104010
CG36
CG37 4822 124 41535 ELECT. 100µF 25V M RA-2 OA10702520
CG38 4822 124 41535 ELECT. 100µF 25V M RA-2 OA10702520
CG43
4822 126 11687 CER. 0.1µF +80%-20% DK98104200
CG48
CG49 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CG50 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CG51
CG52 4822 126 11759 CER. 100pF ±5% CG 50V DD95101300
CG60 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CG61 4822 126 11687 CER. 0.1µF +80%-20% DK98104200
CG62 4822 126 11759 CER. 100pF ±5% CG 50V DD95101300
CG63 4822 126 11759 CER. 100pF ±5% CG 50V DD95101300
CG64 4822 126 11759 CER. 100pF ±5% CG 50V DD95101300
CG65 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CG66 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CG67 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CG68 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CG69 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
CH05
4822 121 10792 FILM CAP 220pF ±5% 100V OF15221540
CH08
CH11 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CH12 4822 124 90362 ELECT. 22µF 50V M RA-2 OA22605020
CH13
4822 126 11687 CER. 0.1µF +80%-20% DK98104200
CH16
CH21 4822 124 41535 ELECT. 100µF 25V M RA-2 OA10702520
CH22 4822 124 41535 ELECT. 100µF 25V M RA-2 OA10702520
CH23 4822 126 11687 CER. 0.1µF +80%-20% DK98104200
CH24 4822 126 11687 CER. 0.1µF +80%-20% DK98104200
CH25 4822 126 11682 CER. 220pF ±10% DK96221300
CH26 4822 126 11682 CER. 220pF ±10% DK96221300
