Marantz CD6003 Service Manual

4
4. TAKING THE DISC OUT OF EMERGENCY
1. Remove the top cover of the player.
2. Remove 2 screws shown in the picture follows.
3. Remove the disc clamper.
4. Now you can remove the disc.
5. SERVICE MODE
There are two modes in the service mode.
[A] Mode to display version information on each
module.
サービスモードには2種類あり、各モジュールのバージョン情報
を表示するモードとラストエラーメッセージを確認するモードがあ
ります。
[A] 各モジュールのバージョン情報等を表示するモード
Model name is Displayed
モデル名表示
CD6003
“STOP”+“NEXT”+“POWER ON”
Version of Front microprocessor is
displayed
Fromtマイコンバージョン表示
Playback time displayed
再生時間表示
Playback time clear?
再生時間クリア確認
Turn on all segment
全点灯
NEXT PREVIOUS
PREVIOUS
Turn off all segment
全消灯
NEXT
Serial number is displayed
シリアル番号表示
Received command displayed
受信コマンド表示
NEXT
Version of USB is displayed
USBバージョン表示
NEXT PREVIOUS
NEXT PREVIOUS
STOP(3sec)
NEXT PREVIOUS
NEXT PREVIOUS
PREVIOUS
Playback time clear
再生時間クリア
PREVIOUS
PLAY
①
②
③
⑥
⑦
④
⑤-a
⑤-b
⑧
Remove those screws
All manuals and user guides at all-guides.com
all-guides.com

Marantz CD6003 Specifications

General

Frequency range	2 - 20000 Hz
Audio formats supported	AAC, MP3, WMA
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.002 %
CD-RW playback	Yes
CD changer	-
Device type	Personal CD player
Cassette deck	No
Product color	Gold, Silver
Channels quantity	2 channels
Disc loading type	Tray
Remote control type	RC002CD
Display type	LCD
Volume control	Rotary
Programmable tracks	30
USB 2.0 ports quantity	1
Power consumption (standby)	0.3 W
Power consumption (typical)	19 W

Weight and Dimensions

Depth	339 mm
Width	440 mm
Height	106 mm
Weight	7000 g
