Marantz DR17 - Exploded View and Parts List

POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
001B GLD 9965 000 00553 FRONT PANEL ASSY GOLD 376K248550
001B
BLK 9965 000 00552 FRONT PANEL ASSY BLACK 376K248500
002B
GLD 9965 000 00555 FRONT PANEL AL GOLD 376K248110
002B
BLK 9965 000 00554 FRONT PANEL AL BLACK 376K248010
003B
GLD 4822 444 40853 CORNER COLUMN AL GOLD 318K063110
003B
BLK 4822 444 40852 CORNER COLUMN AL BLACK 318K063010
015B
GLD 9965 000 00557 WINDOW,PINK 318K158120
015B
BLK 9965 000 00556 WINDOW,BLUE 318K158020
016B
GLD 9965 000 00559 BUSH,FOR TRAY OPENING 376K259110
016B
BLK 9965 000 00558 BUSH,FOR TRAY OPENING 376K259010
017B
GLD 9965 000 00561 FRONT PCB HOLDER GOLD 376K104110
017B
BLK 9965 000 00560 FRONT PCB HOLDER BLACK 376K104010
025B
GLD 9965 000 00563 BUTTON PLAY/STOP/PAUSE 362K270150
025B
BLK 9965 000 00562 BUTTON PLAY/STOP/PAUSE 362K270050
026B
GLD 4822 410 70033 BUTTON OPEN/CLOSE GOLD 318K270130
026B
BLK 4822 410 70028 BUTTON OPEN/CLOSE BLACK 318K270030
027B
GLD 9965 000 00565 BUTTON ERASE GOLD 376K270110
027B
BLK 9965 000 00564 BUTTON ERASE BLACK 376K270010
028B
GLD 9965 000 00567 BUTTON DISPLAY GOLD 376K270120
028B
BLK 9965 000 00566 BUTTON DISPLAY BLACK 376K270020
035B
GLD 9965 000 00569 BUTTON REC GOLD 376K270140
035B
BLK 9965 000 00568 BUTTON REC BLACK 376K270040
036B
GLD 9965 000 00575 BUTTON CD SYNC GOLD 376K270160
036B
BLK 9965 000 00574 BUTTON CD SYNC BLACK 376K270060
045B
GLD 9965 000 00577 BUTTON POWER GOLD 376K270180
045B
BLK 9965 000 00576 BUTTON POWER BLACK 376K270080
047B
GLD 9965 000 00579 KNOB REC GOLD 376K154110
047B
BLK 9965 000 00578 KNOB REC BLACK 376K154010
048B
GLD 9965 000 00580 KNOB PHONE GOLD 284T154240
048B
BLK 4822 411 20336 KNOB PHONE BLACK 284T154310
050B
GLD 9965 000 00582 TRAY LID AL,W15 GOLD 376K063110
050B
BLK 9965 000 00581 TRAY LID AL,W15 BLACK 376K063010
052B
9965 000 00583 TRAY LID RETAINER 376K104060
056B
9965 000 00584 LENS 351H355010
062B
9965 000 00585 CD-R/CD-RW BADGE ON
ESCUTCHEON
376K251010
001D
GLD 9965 000 00587 TOP COVER AL GOLD (SLIT) 318K257140
001D
BLK 9965 000 00586 TOP COVER AL BRACK (SLIT) 318K257040
002D
GLD 4822 502 14425 SCR.THINHEAD 3X8NI 323S010020
002D
BLK 4822 502 21693 SCR.THINHEAD 3X8BL 323S010030
003D
GLD 4822 502 14462 SCR.THINHEAD 3X5NI 318K010020
003D
BLK 4822 502 14461 SCR.THINHEAD 3X5BL 318K010030
010D
GLD 4822 444 40855 SIDE PANEL GOLD 318K249110
010D
BLK 4822 444 40854 SIDE PANEL BLACK 318K249010
010G
4822 462 42134 LEG 291K057010
030G
9965 000 00588 POWER SW.LINK 376K121010
001M
3104 129 21361 CDR MECHA ASSY 376K304500
J001 4822 265 11399 2P MAINS INLET SOT-16C YJ04002360
L001 FN EI-5735 100V 50/60HZ TS15746010
L001 N1B N1G 9965 000 00598 EI-5735 230V 50HZ TS15746020
L001 U1B U1G EI-5735 120V 60HZ TS15746040
W001 FN MAINS CORD MITI
DC-302-J 125V
ZC01802080
W001 N1B N1G 4822 321 11439 MAINS CORD 10A 250V
CLASS-2
ZC01803080
W001 U1B U1G MAINS CORD UL/CSA
10A 125V
ZC01803100
PACKING
001S PACKING CASE DR-17 376K801010
001T
FN USER GUIDE DR-17 F 376K851110
001T
N1B N1G 9965 000 00590 USER GUIDE DR-17 (9 LANG.) 376K851310
001T
U1B U1G USER GUIDE DR-17 U 376K851250
008T 9965 000 00591 SHEET FOR CD-R CD-RW 376K851010
009T
FN QUICK USE GUIDE DR-17 F 376K851020
010T
FN FLY SEET FOR HDCD 376K851030
010T
U1B U1G FLY SEET FOR HDCD 376K851030
001X 4822 466 12204 TRANSPORTATION
PROTECTOR
376K269010
T100 9965 000 00592 REMOTE CONTROLLER
(RC-17DR)
ZK376K0010
W002 4822 321 22611 RCA CONNECTIVE CODE
GOLD
ZD01100010
W003 RCA RC-5 CODE 0.9M ZD00900100
W005 4822 321 22611 RCA CONNECTIVE CODE
GOLD
ZD01100010
1.11 EXPLODED VIEW AND PARTS LIST
1-32
