Marantz DR17 - Page 45

06-99-HT (3104 129 21361)
GUIDANCE FORM
REPAIRABLE UNIT 3104 129 21361
Please fill in this form and return it with the defective unit.
Typenumber
(unit demounted from set)
: DR17/
..................
Serial number :
...................................................
Unit serial number
(CDR Module)
: CDL3610/01;
....
VO
...................
.....
warning: Dismantling of the CDR Module is not allowed. Guarantee will
be invalidated. Only Returned Modules with filled in Guidance
form are accepted
In case CDR-disc has been damaged, please include this damaged disc
with the exchanged CDR Module
DISC DAMAGED? Y/N
DISC INCLUDED? Y/N
INFORMATION GATHERED VIA SERVICE TEST MODE
Switch POWER ON,
Activate OPEN/CLOSE,
Insert test disc SBC444A, or any other CD-Digital Audio disc;
switch POWER OFF,
<PLAY>+<NEXT>+<POWER ON> keep all keys pressed for 2 seconds
During test:
Blinking D on display (about 2 minutes!!);
Blinking B on display (for some seconds).
ERROR INDICATION (on display) according to table below: Y / N
ON DISPLAY IRIS
SYMPTOM CODE
YES *)
DISPLAY TEST RESULT
RAM error
DERR 1
15....
ROM error
DERR 2
16....
EEPROM error
DERR 3
16....
DAIO error
DERR 4
15....
GDIN error
DERR 5
15....
BASIC ENGINE TEST RESULT
Communication bus error
BERR 1
15....
Basic Engine error
BERR 2
15....
Disc test error
BERR 3
16....
*)
insert cross at seen display result.
IN CASE OF NO ERROR INDICATION;
OTHER PROBLEMS OCCURED AT:
PLAYBACK CD CDR
Unfinalised
CDR
Finalised
CDRW
Unfinalised
CDRW
Finalised
Y/N
RECORDING CD CDR
Unfinalised
CDR
Finalised
CDRW
Unfinalised
CDRW
Finalised
Y/N -----
IRIS CONDITION CODE:
DESCRIPTION CONDITION CODE
Constantly 1...
Intermittently 2...
After a while 3...
In a hot environment 4...
In a cold environment 5...
